Naphthalene, the simplest polycyclic aromatic hydrocarbon and a compound long flagged as carcinogenic and mutagenic, may soon meet its match on an atomically engineered sheet of carbon. A new computational study published in Discover Green Chemistry reports that decorating nitrogen and Group 13 co-doped graphene with a single transition metal, titanium, transforms the surface from a weak, essentially passive adsorbent into a powerful and electronically responsive trap for the pollutant. Using density functional theory, the research team from the University of Calabar and Modibbo Adama University in Nigeria showed that the simple act of anchoring titanium atoms onto B-, Al- or Ga-nitrogen co-doped graphene can boost naphthalene binding from a few electron-volts of physisorption to nearly ten electron-volts of strong, partly covalent interaction, a difference that could redefine how graphene-based sensors and water-treatment materials are designed.
The motivation behind the work is grounded in a growing environmental problem. Polycyclic aromatic hydrocarbons accumulate in aquatic systems worldwide as industrialization accelerates, and naphthalene is among the most prevalent of them. The molecule is hydrophobic, flammable, volatile and chemically stable in water, and long-term exposure has been linked to genetic damage and the disruption of red blood cells, leading to anemia. Adsorption remains the most widely accepted treatment for removing such organic pollutants from wastewater, and carbonaceous materials, from activated carbons to carbon nanotubes and graphene derivatives, have shown strong performance. Yet the authors highlight a persistent gap: few studies have assessed naphthalene adsorption in the presence of heavy metals, salts and phenols that coexist in real effluents, and chemical modification of adsorbents with amines or surfactants risks leaching secondary pollutants into treated water.
The design logic of the new surfaces follows a cleaner path. Boron and nitrogen are the natural choices for doping graphene because they bracket carbon in the periodic table, and their electronegativities make them attractive for metal-free catalytic surfaces. Nitrogen-gallium co-doped graphene has already proven itself as a gas sensor for ozone, transforming chemically inert graphene into a defect-rich, electronically tuned and highly reactive material. Group 13 elements act as p-type dopants that create electron-deficient regions, and aluminum-doped graphene in particular shows markedly stronger adsorption of small molecules than pristine or nitrogen-doped sheets. The remaining piece was titanium: because its d-orbitals act as strong adsorption centers capable of bonding with both adsorbates and lattice nitrogen, the researchers reasoned that a single titanium atom per surface could amplify capture without any additional chemical functionalization, in keeping with green chemistry principles of reusable, stable, minimally modified materials.
Computationally, the study was demanding in its rigor. All calculations used the wB97XD exchange-correlation functional, chosen because it explicitly includes empirical dispersion corrections and long-range exchange, both essential for describing the van der Waals forces that govern how aromatic molecules stack against graphene. Metal atoms were treated with the LANL2DZ basis set and effective core potentials to capture relativistic effects economically, while all non-metal atoms used the def2-SVP split-valence basis with polarization functions. The team ran a full battery of analyses: geometry optimization, frontier molecular orbital analysis, natural bond orbital analysis, density of states calculations, non-covalent interaction plots, and quantum theory of atoms in molecules, alongside charge transfer, dipole moment and back-donation descriptors. Titanium-containing systems were modeled as high-spin triplets to account for unpaired d-electrons, and adsorption energies were computed from the difference between the total complex energy and the sum of the bare surface and isolated naphthalene energies.
Structurally, the results were reassuring. After relaxation, every system preserved the characteristic hexagonal lattice of pristine graphene, with only localized distortions around the dopant and titanium sites. Carbon-carbon bonds stayed within the typical range of 1.35 to 1.46 angstroms, nitrogen-carbon bonds fell between 1.38 and 1.46 angstroms, and the Group 13 to carbon bonds lengthened from 1.48 to 1.74 angstroms, tracking the increasing covalent radii from boron to gallium. Titanium introduced more dramatic local changes, with titanium-carbon and titanium-nitrogen distances between 1.88 and 2.33 angstroms and much longer titanium-boron separations reaching 3.82 angstroms in the Al-based system. These localized distortions, the authors note, promote enhanced orbital hybridization around the adsorption site, precisely where the electronic action happens.
The electronic structure analysis revealed the most striking contrast between decorated and undecorated surfaces. Without titanium, naphthalene adsorption produced moderate band gaps of 2.612 electron-volts for the boron-nitrogen system and 2.248 electron-volts for the gallium-nitrogen system, signatures of weak, pi-pi driven physisorption. Titanium decoration fundamentally altered this picture: after adsorption, the band gaps jumped to 3.83 electron-volts for NAP-Ti-Al-N@GP, 4.075 electron-volts for NAP-Ti-B-N@GP, and 2.992 electron-volts for NAP-Ti-Ga-N@GP. Density of states analysis traced these changes directly to titanium d-orbital contributions near the Fermi level, meaning the band gap shifts correspond to genuine conductivity modulation, exactly the property a resistive sensor exploits. In the Ti-gallium system, the pronounced overlap of occupied and virtual orbitals near the Fermi level correlated with the strongest adsorption energy of the entire study.
Adsorption energies told the headline story. All undecorated surfaces bound naphthalene favorably, but modestly: gallium-nitrogen graphene led at minus 4.599 electron-volts, aluminum-nitrogen followed at minus 4.381, and boron-nitrogen lagged at minus 3.401. Adding titanium changed the ranking and the magnitude. NAP-Ti-Ga-N@GP delivered minus 9.551 electron-volts, the most negative adsorption energy of any configuration, while NAP-Ti-Al-N@GP reached minus 5.333 and NAP-Ti-B-N@GP minus 3.456. Titanium binding itself proved energetically stable across all three substrates, with binding energies clustered tightly between 18.462 and 18.549 atomic units, suggesting that whichever Group 13 partner is chosen, the metal anchors firmly. Natural bond orbital analysis reinforced the picture, with stabilization energies rising to 240.88 kilocalories per mole for Ti-Al-N@GP and post-adsorption values reaching 1560.67 kilocalories per mole for the Ti-boron complex.
The bonding analysis explained why titanium matters so much. Non-covalent interaction plots showed widespread green isosurfaces spanning the naphthalene-graphene interface on undecorated surfaces, the visual fingerprint of van der Waals pi-stacking, while titanium systems developed localized red and blue isosurfaces near the metal center indicating stronger attractive interactions and a shift from physisorption toward chemisorption. QTAIM confirmed the same transition quantitatively: undecorated systems displayed the positive Laplacians and moderate electron densities of weak closed-shell interactions, whereas titanium-containing complexes showed high electron densities at bond critical points, negative total energy densities, and low kinetic-to-potential energy ratios, all markers of partial covalent, metal-pi orbital hybridization. Perhaps most elegantly, the charge analysis revealed a Dewar-Chatt-Duncanson type donation-back-donation mechanism: naphthalene first donates pi-electron density to the electron-deficient doped surface, then the dopant and titanium orbitals push density back into the pi-star orbitals of naphthalene, with back-donation energies rising from around 0.3 for undecorated systems to 0.509 for Ti-B-N@GP.
The practical verdict is that titanium-gallium-nitrogen co-doped graphene offers the best combination of strong adsorption and electronic response, making it the leading candidate for a naphthalene sensor, while titanium-boron systems exhibit the strongest bidirectional charge transfer and correspondingly high sensing potential. Compared with conventional activated carbons, which rely on porosity and physical trapping, these engineered surfaces operate through tunable electronic interactions that are potentially reversible, an advantage for sensor regeneration and reuse. The authors also emphasize the sustainability angle: computational pre-screening of this kind minimizes experimental trial-and-error, solvent consumption and chemical waste. The predictions now await laboratory validation, along with exploration of other transition metal decorations and selectivity tests against competing aromatics, but the message is clear, a single judiciously placed titanium atom can turn a passive carbon sheet into an active, readable detector of one of the environment’s most persistent pollutants.
Subject of Research: DFT study of naphthalene adsorption and sensing on titanium-decorated nitrogen and Group 13 co-doped graphene
Article Title: Adsorption of naphthalene on nitrogen doped and Group 13 (B, Al, Ga) co-doped graphene surfaces with additional titanium decoration
Article References: Inah, B. E., John, D., Nyong, E. B., Anyama, C. A., Nelson, F. A., & Ayi, A. A. (2026). Adsorption of naphthalene on nitrogen doped and Group 13 (B, Al, Ga) co-doped graphene surfaces with additional titanium decoration. Discover Green Chemistry, 1(1), Article 37. https://doi.org/10.1007/s44509-026-00014-2
Image Credits: AI Generated
DOI: 10.1007/s44509-026-00014-2
Keywords: graphene, naphthalene, titanium decoration, DFT, adsorption, doped graphene, sensors, water pollution, polycyclic aromatic hydrocarbons, green chemistry, charge transfer, band gap
