Every year, hundreds of thousands of people worldwide receive the most feared diagnosis in neurology: glioblastoma, the most common primary malignant brain tumor in adults, notorious for its ability to infiltrate the brain far beyond what any MRI can see. For decades, radiation oncologists have fought this invisible invasion with a blunt but trusted tool: after outlining the visible tumor on anatomic MRI, they simply expand that outline outward by roughly two centimeters in every direction, as if the tumor were a balloon inflating evenly through the skull. A new proof-of-concept study published in the Journal of Neuro-Oncology argues that this one-size-fits-all circle is anatomically naive, and that the brain’s own wiring may hold the key to more intelligent targets.
The logic behind the conventional approach is simple: because glioblastoma cells creep microscopically into surrounding tissue, the radiation field must be larger than the visible tumor. But histopathologic and preclinical studies have long shown that glioblastoma does not spread isotropically. Instead, it migrates preferentially along large white matter pathways, the bundled fiber tracts that connect distant brain regions. The tumor behaves less like an inflating balloon and more like water flowing through a network of pipes, racing along highways of myelinated axons while slowing at natural barriers. Yet this biological reality has never been systematically built into radiotherapy planning, until now.
A team led by Michael Wahl of the University of California, San Francisco, together with colleagues across UCSF’s radiation oncology, neurology, radiology and neurosurgery departments, has now translated that insight into a clinically workable technique. Their method uses diffusion-weighted MRI, which measures how freely water molecules diffuse through tissue. In organized white matter, water diffuses preferentially along the axis of the fiber bundles, a phenomenon called anisotropy. Tractography algorithms exploit this signal to reconstruct the trajectories of white matter fiber pathways throughout the entire brain, effectively drawing a wiring diagram of each individual patient.
The technical pipeline behind the study is a careful exercise in modern imaging science. Thirteen glioblastoma patients underwent 55-direction high angular resolution diffusion imaging on a 3 Tesla scanner as part of their postoperative radiation planning MRI, an acquisition of only seven to eight minutes. After correcting the data for head motion and eddy-current distortion using the FMRIB Software Library, the researchers fit both a tensor model and a higher-order Q-ball model with the open-source DIPY package, the latter to accurately resolve regions where fiber bundles cross. White matter, defined as voxels with fractional anisotropy above 0.15, was seeded densely, and a residual-bootstrap tractography approach estimated fiber orientations probabilistically, terminating streams when anisotropy fell below threshold or fibers bent more than sixty degrees.
Here is where the innovation crystallizes. The team selected all tractography streamlines passing within five millimeters of the visible tumor, the gross tumor volume delineated from the surgical cavity, contrast-enhancing regions and mass-like T2-FLAIR abnormality. From this subset they generated a scalar map in which every voxel stores its minimum white matter path length to the tumor, the shortest distance along actual fiber tracts rather than straight-line distance. The result is an anatomically informed expansion: the target flows along the superior cingulum bundle in one patient, crosses to the opposite hemisphere through the splenium of the corpus callosum in another, and in a third tracks along the inferior longitudinal fasciculus, precisely the routes along which those tumors later spread. In every one of the thirteen cases, the resulting contours respected natural anatomic boundaries that the standard circular expansion ignored.
The payoff appears in the numbers. When the researchers generated clinical target volumes by thresholding the path length maps at two centimeters and compared them, within the same patient, to the guideline-conformant two-centimeter isotropic expansion, the tractography-based volumes were a median of 67 cubic centimeters smaller, roughly a nineteen percent reduction, a difference that reached statistical significance. The one-centimeter variant shrank targets even more dramatically, by 39 percent on average, though at the cost of missing several recurrences captured by the standard volume. At three centimeters, the tractography volume converged with the standard one, as expected. These volumes were imported directly into the RayStation treatment planning system, demonstrating that the approach is compatible with routine clinical workflows rather than confined to research software.
The more consequential question is whether these sculpted volumes actually contain the places where tumors come back. To answer it, the team performed a patterns-of-failure analysis, rigidly registering each patient’s recurrence MRI to the planning scans and classifying recurrences as central, in-field, marginal or distant relative to each target definition. The median time to recurrence was twelve months. Ten of the thirteen recurrence volumes fell entirely within the conventional isotropic target, but twelve of thirteen were encompassed by the two-centimeter tractography-based volume, all while that volume was substantially smaller. In two cases, the recurrent tumor was clearly infiltrating along a major white matter tract inside the tractography target but outside the standard one, exactly the failure mode the technique was designed to prevent.
The clinical context makes these findings timely. Historical teaching held that ninety percent of glioblastoma recurrences occur within a two-centimeter margin of the original tumor, a figure that discouraged tinkering with target delineation. But more recent studies of patients treated with concurrent temozolomide, particularly those whose tumors carry methylation of the MGMT promoter and are therefore more drug-sensitive, have shown marginal or distant recurrence rates approaching forty percent, suggesting that current volumes may undertreat pockets of microscopic disease in some patients. At the same time, generous circular expansions irradiate substantial volumes of healthy brain, raising the specter of radiation necrosis and long-term neurocognitive decline. An approach that could simultaneously tighten targets and extend them along true routes of invasion promises the rarest of things in oncology: better coverage with less collateral damage.
The researchers are appropriately measured about what their study can and cannot claim. Thirteen patients cannot prove a statistical reduction in marginal or distant recurrences, and the pattern-of-failure analysis was observational and hypothesis-generating. Even demonstrating that a recurrence fell within a tractography target does not prove that treating that volume would have prevented it, since most patients still recur within the high-dose region regardless of technique. The small sample also prevented confident optimization of the tracking parameters and path length thresholds, and no dosimetric analysis of organ-at-risk sparing has yet been performed. Validation in a larger prospective cohort, with formal assessment of normal brain sparing through dose-volume statistics, is the clearly stated next step.
Still, as a proof of concept, the study is striking in its feasibility and simplicity. The imaging sequence adds only minutes to a standard planning MRI, the analysis relies on open-source tools, and the output drops directly into commercial treatment planning software. What the UCSF team has shown is that the brain’s own anatomy can be enlisted as a map of where an incurable tumor is likely to travel next, replacing a geometric convention inherited from decades-old CT studies with a personalized, biologically grounded contour. If larger trials confirm that two centimeters along a nerve fiber tract is worth more than two centimeters in a straight line, the humble circle that has defined glioblastoma radiotherapy for a generation may finally be retired, and one of medicine’s grimmest diagnoses may gain a small but meaningful edge.
Subject of Research: Tractography-based clinical target volume delineation for glioblastoma radiotherapy planning
Article Title: White matter pathlength maps from diffusion-weighted MRI tractography for radiotherapy target planning in glioblastoma
Article References: Wahl, M., Chapman, C. H., Morin, O., Jordan, K., Henry, R. G., Chang, S. M., Villanueva-Meyer, J. E., Mukherjee, P., Theodosopoulos, P., McDermott, M. W., Berger, M. S., Sneed, P., Braunstein, S. E., & Lupo, J. M. (2026). White matter pathlength maps from diffusion-weighted MRI tractography for radiotherapy target planning in glioblastoma. Journal of Neuro-Oncology, 179(3), Article 102. https://doi.org/10.1007/s11060-026-05789-9
Image Credits: AI Generated
DOI: 10.1007/s11060-026-05789-9
Keywords: glioblastoma, diffusion-weighted MRI, tractography, radiotherapy planning, white matter, clinical target volume, patterns of failure, tumor recurrence, neuro-oncology, UCSF, temozolomide, medical imaging
