Ultraviolet disinfection has quietly become one of the most important technologies in the global effort to deliver safe drinking water, and now a team of researchers has shown that the secret to better UV reactors may lie not in more powerful lamps or cleverer electronics, but in the shape of the walls themselves. In a new computational study published in Results in Engineering, Mahyar Najafian, Mohammadreza Soufivand, and Annunziata D’Orazio report the geometric optimization of a corrugated tubular UV reactor using response surface methodology, demonstrating that carefully sculpted internal surfaces can boost the average cumulative UV dose delivered to water by roughly a third while keeping the added hydraulic penalty surprisingly modest. The finding arrives at a moment when access to microbiologically safe water remains a serious challenge in developing countries and rural communities, where waterborne disease continues to threaten public health and chemical disinfection options face growing scrutiny.
The appeal of UV irradiation as a disinfection strategy is well established. Unlike chlorination, ultraviolet treatment inactivates a broad spectrum of pathogenic microorganisms without adding chemicals to the water, without producing harmful disinfection by-products, and without inducing the kind of microbial resistance that worries public health officials. Water produced by desalination systems and wastewater reclamation plants cannot be supplied directly for consumption; it must pass through a final disinfection stage before it is safe to drink. UV reactors fill that role in a growing number of facilities worldwide. But the performance of any such reactor depends on a delicate interplay between radiation transport and fluid dynamics: microbes that zip through shadowed zones too quickly receive an insufficient dose, while engineers who try to slow the water down often pay for it in pressure losses and pumping costs. The new study attacks exactly this trade-off by reshaping the reactor’s interior.
The research team focused on a tubular UV reactor with an outer tube diameter of 89 millimeters and a central UV lamp diameter of 20 millimeters, a configuration typical of annular UV disinfection reactors used for desalinated and reclaimed water streams. Rather than modifying the entire device, the investigators isolated a 60-centimeter-long central segment and subjected only that test section to geometric modification, keeping the upstream and downstream sections smooth so that fully developed flow conditions would be guaranteed at the inlet and outlet of the design region. Within this segment, a corrugated pattern was applied to the inner surface of the outer tube. The corrugation geometry was fully characterized by three independent parameters: the inward radial depth of the corrugation, designated as parameter a, and two axial dimensions of each corrugation element, the groove length b and the ridge length c. The parameter ranges, with depths of 7, 14, and 21 millimeters and groove and ridge lengths of 30, 60, and 90 millimeters, were chosen to balance geometric feasibility within the fixed reactor diameter, manufacturability constraints, and a controlled number of corrugation elements along the design section.
To explore the design space systematically, the researchers adopted a 13-run, three-factor Box-Behnken design of experiments, comprising 12 edge points and one center point. Each configuration was simulated under identical conditions: a constant flow rate of 25 gallons per minute and a UV lamp power of 40 watts. The simulations were performed in COMSOL Multiphysics version 6.2, which solved both the turbulent flow field and the optical radiation field. The hydrodynamics were modeled using the Reynolds-averaged Navier-Stokes equations coupled with the standard k-epsilon turbulence model, while the propagation of ultraviolet rays through the absorbing water medium was described by geometrical optics, governed by Hamilton’s equations for ray position and wave vector. UV absorption by the water was incorporated through the imaginary part of the refractive index, tied directly to the measured spectral transmittance of the medium. The resulting fields were then exported to MATLAB, where Lagrangian particle tracking was used to follow 1,000 passive, massless fluid particles through the reactor, integrating their trajectories with a fourth-order Runge-Kutta scheme and a fixed time step of 10^-4 seconds. Each particle accumulated UV dose by integrating the local fluence rate along its path, and the response variable was defined as the histogram-based mean cumulative UV dose of the particles reaching the reactor outlet, weighted across dose bins 5 millijoules per square centimeter wide.
Before running the optimization, the team subjected their numerical framework to rigorous validation. A grid independence study, performed on the most geometrically complex configuration, compared five meshes of increasing density and showed that the relative difference in predicted UV dose between the two finest meshes fell below 4 percent, while the pressure drop changed by only about 2.9 percent. The final adopted mesh contained 739,008 cells, with local refinement near the corrugated wall surfaces and around the lamp, and its quality metrics, including skewness and condition-number measures, remained within acceptable ranges. The radiative model was then validated against an established MPSS-based reference model by comparing the circumferentially averaged UV fluence rate as a function of radial distance, achieving an average deviation below 5 percent across the entire radial domain. The hydrodynamic component was separately validated against experimental velocity measurements from a classical backward-facing step flow study, with the predicted streamwise velocity profile matching the measured data closely at the sampled location. Together, these checks gave the team confidence that the coupled flow-radiation-particle framework was physically trustworthy before any design conclusions were drawn.
The results revealed both the promise and the subtlety of corrugated geometries. Across the 13 simulated cases, the mean cumulative UV dose ranged from 38.927 millijoules per square centimeter in the worst configuration to 51.366 millijoules per square centimeter in the best, an improvement of nearly 32 percent. Notably, the boundary configurations that performed poorly also tended to exhibit the highest pressure loss ratios, reaching 17.2 percent above the reference case, indicating that extreme geometric combinations can simultaneously degrade UV effectiveness and increase hydraulic resistance. The central design point of the Box-Behnken matrix, with all three parameters at intermediate levels, offered a vivid picture of the underlying physics: particle trajectories and velocity contours showed strong acceleration and directional redistribution near the entrance of the corrugated section, the formation of secondary flow structures and recirculation zones, and enhanced radial transport that extended the time particles spent in the irradiated domain. These features promote dose accumulation, but the intensified mixing near the geometric protrusions also generates additional shear stress, which explains the moderate rise in pressure loss observed in some configurations.
The statistical treatment of the simulation results was equally rigorous. A second-order quadratic response surface model was fitted to the data, incorporating linear, quadratic, and two-factor interaction terms for the three coded geometric variables. Analysis of variance confirmed that the overall quadratic model was statistically significant at the 95 percent confidence level, with an F-statistic of 15.2 and a corresponding p-value of 0.0234. The fitted coefficients revealed strong positive linear contributions from the corrugation depth and the groove length, tempered by negative quadratic terms that captured the diminishing returns and eventual penalties of pushing these dimensions too far. This structure reflects a physical reality that reactor designers have long suspected but rarely quantified: corrugations help by redistributing flow and lengthening exposure paths, but excessive depth or overly long features can create shadow zones, overly fast channeling, or excessive drag. The response surface approach makes these competing effects explicit and, crucially, allows the design space to be searched mathematically rather than by trial and error.
The broader context of this work is a field that has been converging on the same lesson from many directions. Previous studies have shown that baffles can improve hydraulic mixing and enhance pathogen removal by up to 70 percent in UV systems; that ring baffles in UV reactors can boost disinfection performance by 36 to 69 percent by aligning flow patterns with UV radiation; that serpentine and helical UV-C LED reactor geometries can substantially raise fluence and microbial inactivation; and that optimized reflector modules can increase UV fluence by factors of up to 30 at some distances from the source. Computational fluid dynamics has increasingly been paired with Monte Carlo simulations, polynomial chaos expansions, and multi-objective genetic algorithms to push reactor design forward. What distinguishes the new study is its focus on continuous internal geometric modification, the corrugation itself, rather than on discrete add-on elements or lamp arrangements, and its use of a structured design of experiments combined with response surface methodology to quantify exactly how corrugation dimensions shape residence time distribution and cumulative UV dose. The authors note that the role of corrugation dimensions in shaping these coupled phenomena has not been comprehensively quantified before, making this configuration one that had not previously been probed.
The implications extend well beyond the specific reactor studied. The required pumping power across the 13 configurations ranged only from about 43 to 50.4 watts, meaning that significant gains in radiative performance could be achieved with only moderate hydraulic penalties. For decentralized and household-scale treatment systems, and for rural communities that rely on off-grid or low-energy solutions, the difference between a reactor that wastes pump energy and one that extracts maximum disinfecting power from each watt of lamp input can determine whether the technology is viable at all. The same principles apply to larger municipal installations, where pressure drop translates directly into operational cost. And because the study deliberately selected an optimization objective, the mean cumulative UV dose, that is organism-independent, the design guidance is broadly applicable, even though the researchers did not quantify organism-specific log reduction in this study; the survival analysis was instead framed around a nominal inactivation constant representative of MS2 bacteriophage, a common surrogate in UV reactor evaluation.
There are, of course, limitations to acknowledge. The study is entirely computational, based on one-way coupling between the flow-radiation solution and the particle tracking, with turbulent dispersion of particles neglected and motion governed by advection in the mean flow field. Real reactors face additional complications, including fouling driven by water quality, sleeve aging, and the non-ideal hydraulics that have long plagued scale-up efforts in water treatment. The authors themselves frame their contribution as offering practical design guidance rather than a finished product, and the validated numerical framework is the real deliverable: a tool that can now be used to interrogate other geometries, other flow rates, and other optical conditions without fabricating each candidate in metal. Still, the message to the field is clear and likely to resonate: when it comes to UV water disinfection, the geometry of the reactor is not a passive container but an active optical and hydraulic instrument, and shaping it deliberately, corrugation by corrugation, can squeeze substantially more protection out of the same lamp.
Subject of Research: Geometric optimization of a corrugated tubular ultraviolet water disinfection reactor using response surface methodology, computational fluid dynamics, and Lagrangian particle tracking to maximize mean cumulative UV dose while controlling hydraulic pressure loss.
Subject of Research: Technology and Engineering
Article Title: Geometric optimization of a corrugated ultraviolet reactor using response surface methodology for enhanced ultraviolet dose and controlled hydraulic loss
Article References: Najafian, M., Soufivand, M., & D’Orazio, A. (2026). Geometric optimization of a corrugated ultraviolet reactor using response surface methodology for enhanced ultraviolet dose and controlled hydraulic loss. Results in Engineering, 32, Article 112736. https://doi.org/10.1016/j.rineng.2026.112736
Image Credits: AI Generated
DOI: 10.1016/j.rineng.2026.112736
Keywords: UV water disinfection, corrugated reactor, response surface methodology, computational fluid dynamics, cumulative UV dose, hydraulic pressure loss, Box-Behnken design, Lagrangian particle tracking, geometrical optics, reactor optimization
