Electric vehicles were supposed to be the quiet end of the automobile age, and in one sense they delivered: the broadband roar of the internal combustion engine is gone. But into that sudden silence has crept something arguably more irritating — a thin, high-frequency whine that rises and falls with every press of the accelerator, traceable to the power electronics that convert battery direct current into the alternating current that spins the motor. Engineers at Otto von Guericke University Magdeburg in Germany now report a disarmingly elegant fix. By filling the unused cavities of an electric inverter’s lid with granulate recycled from end-of-life tyres, they cut structural vibration by 9.7 decibels at the component’s most troublesome resonance near 897 hertz and lowered radiated sound pressure by as much as six decibels — without adding meaningful mass, redesigning a single part, or making any structural or geometric modification to the module at all.
The phenomenon the team tackled is a direct consequence of electrification. In combustion vehicles, engine noise acted as an acoustic blanket, masking a crowd of smaller contributors, from drivetrain harmonics to tire–road interaction, aerodynamic excitation and cooling fans. Remove the engine and the industry is left with what researchers call an “acoustic void”: a cabin quiet enough that previously masked sources become newly audible — and newly annoying. Consumers and manufacturers have grown correspondingly sensitive to subtle vibroacoustic phenomena, while legislative standards continue to tighten external noise and vibration targets. Within this revised landscape, the electric drive unit — high-speed motor, single-stage gearbox, power electronics and battery system — has become the focus of attention, with electric motors and power electronic modules flagged as significant sources of high-frequency excitation that reach occupants as both structure-borne and airborne noise. The result is that tonal emissions from power electronics now sit near the top of every automaker’s noise, vibration and harshness agenda, even though the vehicle as a whole is far quieter than its predecessor.
The specific target of the new study is the power electronic module, or PEM, the inverter at the heart of the electric drive unit. Contemporary architectures, exemplified by BMW’s fifth-generation drive system, integrate the electric motor, transmission and inverter within a single compact housing. To switch current at high speed, the inverter operates under pulse width modulation, a scheme whose rapid switching generates high-frequency harmonics that induce radial force waves inside the module. Those forces frequently coincide with structural resonances of the casing, amplifying vibration and radiated noise. Because PEM housings are deliberately thin-walled to save space and mass, they are inherently susceptible to vibrational amplification and to transferring energy into adjacent mounting structures — which threatens not only acoustic comfort but long-term reliability and energy efficiency. Industrial collaborators told the Magdeburg group that inverter-induced tonal noise at critical frequencies has repeatedly been identified as a primary contributor to user dissatisfaction.
Existing countermeasures involve awkward trade-offs. Software strategies such as optimizing modulation techniques or shifting the switching frequency struggle to deliver consistent results across a converter’s entire output range. Mechanical fixes — thickening cooling-duct cover plates, adding internal ribs, optimizing gear micro-geometry, or upgrading bearing quality, which one study showed can cut vibration by up to 16 decibels — focus on the motor, gears or bearings rather than the inverter itself. Vibroacoustic metamaterials have demonstrated genuine promise on power electronics lids, achieving a five-decibel noise reduction in a test vehicle, but at a steep mass cost: one sheet-metal design added roughly 83 percent more mass than the lid it modified, a plastic-film variant 40 percent, and a conventional bitumen damping layer 30 percent. Active-passive isolation schemes and acoustic shielding enclosures exist for inverters but are constrained by packaging space, add excessive mass or demand complex structural modification. Particle dampers — containers of loose granular material that dissipate vibrational energy through inter-particle friction and collisions — have long looked attractive, yet studies using steel, cast iron or tungsten particles report a persistent acoustic side effect: high-energy particle impacts inside the enclosure can raise airborne noise even as vibration falls.
The Magdeburg team — Braj Bhushan Prasad, Tommy Luft and Hermann Rottengruber of the Institute for Engineering of Products and Systems — had spent years refining particle damping for wind turbine generators and blades, where they built and experimentally validated a design framework. Among the granular materials they screened, one stood out: rubber granulate milled from end-of-life tyres. The material used here has a bulk density of 465 kilograms per cubic metre, with particle diameters spanning 3.28 millimetres at the 10th percentile to 6.40 millimetres at the 90th, and a median of 4.60 millimetres. Rubber combines efficient vibration attenuation with low added mass and superior durability under cyclic loading and fluctuating thermal environments — conditions that degrade lesser materials in real service, as the team’s earlier studies on granulate mixtures and dynamic loading confirmed. The central question was whether design parameters developed for wind turbines could transfer directly to an automotive inverter with no additional optimization and, crucially, no modification of the component itself.
Validation proceeded in carefully staged phases. First, the lid was tested in isolation, suspended on a thin elastic rope from a Bosch profile to approximate free-free boundary conditions, and struck with an impact hammer carrying an integrated force transducer. Two excitation points ensured that a broad spectrum of vibration modes was activated, impacts were applied normal to the surface to excite the out-of-plane bending modes most relevant to noise radiation, and four accelerometers bonded to the lid captured the response over a 20-to-1100-hertz band on a Müller-BBM PAK MKII acquisition system running PAK 6.2 software. Filling the lid’s cavities with rubber granulate suppressed resonances across the board: one sensor recorded two resonances, near 50 hertz and above 400 hertz, and the damper virtually eliminated the amplitude at the 50-hertz peak, while closely spaced resonances at 670 and 704 hertz were markedly attenuated. The lid was then fastened to the PEM base with thirteen screws tightened to a calibrated three newton-metres, and the damping persisted at every sensor position, indicating a system-wide rather than localized effect. Hammer tests revealed broadband effectiveness stretching to 5000 hertz — beyond the 2000-hertz range documented in the team’s earlier wind-turbine work, and notable because metallic-particle designs typically excel only at higher frequencies.
Two engineering decisions proved decisive. Rather than designing separate particle containers, the researchers used the lid’s own cavities exactly as supplied by their industrial partner, whose confidentiality requirements mean the geometry is published only in normalized form relative to a reference length. To retain the granulate under elevated operating temperatures, they sealed the cavity with a steel sheet just 0.15 millimetres thick, applying the team’s “thin wall cavity” concept: a skin far thinner than the primary structure vibrates at high amplitude and efficiently pumps kinetic energy into the granular medium. A control experiment with a polyester fabric net, holding the rubber mass and distribution identical, produced only negligible damping. The physics explains why: the fabric’s high internal damping and distributed deformation dissipate vibrational energy within its own fibres, whereas the stiff, resonant steel sheet transmits energy into the cavity where the particles can grind, collide and dissipate it.
The decisive trial came on a full electric powertrain test bench, with the damped PEM mounted on the motor inside an anechoic chamber and acceleration measured normal to the lid surface, the direction that dominates airborne noise radiation for plate-like structures. Under full-load operation during a speed sweep from 50 to 10,000 revolutions per minute, three pronounced acceleration peaks emerged at roughly 557, 768 and 926 hertz, with nothing significant below 400 hertz. The damper delivered about 5.5 decibels of attenuation at the third peak, inside the critical 800-to-1100-hertz band that the industrial partner associates strongly with audible cabin noise — though little at the first two peaks, possibly because the lid’s mode shapes leave part of the granulate inactive, a hypothesis the team intends to test with operational modal analysis under load. Under stationary full-load operation at constant speed and torque, the payoff was unambiguous: vibration amplitude at the dominant resonance near 897 hertz fell by 9.7 decibels, and summed vibration levels dropped from 147.8 to 141.8 decibels. The acoustic signature followed suit. Sound pressure levels in the 860-to-1000-hertz band fell from 83.93 to 78.78 decibels — an overall reduction of roughly 5.15 decibels — with about five decibels shaved from the dominant peak near 900 hertz and three to four decibels at neighbouring resonances around 880 and 926 hertz, while the damped spectrum lay consistently below the reference across the entire band.
What makes the result remarkable is its economy. Competing metamaterial concepts bought comparable acoustic wins with double-digit percentage mass penalties and structural redesign; metallic particle dampers traded vibration reduction for noise. The rubber-granulate damper, by contrast, is passive, lightweight and non-invasive, built from recycled waste, and demanded no changes to a component that was otherwise production-ready — the researchers explicitly preserved the integrity and mass of the original structure, sealing the granulate behind a closure that does not alter the internal geometry. The authors argue the approach enhances acoustic comfort, durability and efficiency in equal measure, and they see a clear road ahead: optimizing the distribution and filling ratio of the granulate, validating durability under coupled thermal and mechanical stresses representative of years of vehicle service, and extending the concept to other noise-critical subsystems such as electric motor housings and battery enclosures. The open-access study, published in Automotive and Engine Technology, suggests that one of the most stubborn nuisances of the electric era may be quelled by something as humble as shredded old tyres — tucked quietly into the lid of the box that drives the future of mobility.
Subject of Research: Passive reduction of vibration and noise in electric vehicle inverter enclosures (power electronic modules) using particle dampers filled with recycled rubber granulate from end-of-life tyres.
Article Title: Development of a passive noise control approach for vibroacoustic and acoustic reduction in electric vehicle inverters using particle dampers
Article References: Prasad, B. B., Luft, T., & Rottengruber, H. (2026). Development of a passive noise control approach for vibroacoustic and acoustic reduction in electric vehicle inverters using particle dampers. Automotive and Engine Technology, 11, Article 8. https://doi.org/10.1007/s41104-026-00170-4
