Over-Discharge Leaves a Fingerprint: Impedance Spectroscopy Tracks Hidden Battery Damage

Every lithium-ion battery user has heard the warning: never let your battery drain completely. Deep discharge, or over discharge, is one of the quietest killers of rechargeable cells, degrading performance long before any dramatic failure becomes visible. Now a study from Daegu University in South Korea has shown exactly how that damage announces itself in the electrical signature of a polymer lithium-ion battery, offering a potential early-warning system for the batteries that power electric vehicles, smartphones, and grid storage. The research, published in the journal Ionics by Mangesh Subedi and Hae Kyung Jeong, uses electrochemical impedance spectroscopy, a technique that probes a battery with alternating currents and listens to how the cell responds, to map the damage caused by pushing a battery below its safe voltage floor.

Electrochemical impedance spectroscopy, or EIS, works by applying a small sinusoidal voltage or current perturbation across a range of frequencies and measuring the cell’s response. At high frequencies, the technique reveals the resistance that ions and electrons encounter as they move through electrolytes and across interfaces. At low frequencies, it exposes the slower processes of diffusion, the way lithium ions wander through electrode materials to find their storage sites. By fitting the resulting spectra to equivalent circuit models, researchers can separate these contributions and assign numerical values to them. In this study, the two most telling parameters were the charge transfer resistance, denoted R-CT, which describes the energetic barrier that lithium ions must overcome to cross the electrode-electrolyte interface, and the Warburg impedance, W, which captures the resistance to solid-state diffusion deep within the electrodes.

The team systematically varied the state of charge, or SOC, of polymer lithium-ion cells and recorded impedance spectra at each point, paying particular attention to what happens when the cells are driven into the over-discharge regime. The results revealed a striking asymmetry between the high and low ends of the voltage window. In the high state-of-charge region, spanning voltages from 4.2 volts down to 3.7 volts, the charge transfer resistance increased steadily while the Warburg impedance remained relatively steady. This makes physical sense: when a cathode is nearly full of lithium or an anode is nearly empty, the interfacial kinetics change, but the diffusion pathways through the bulk electrode material remain largely intact.

The picture changed dramatically in the low state-of-charge and over-discharge zone, covering voltages from 3.6 volts down to 2.0 volts. Here the researchers observed a significant rise in the Warburg impedance alongside a drop in the charge transfer resistance. This combination signals that the dominant limitation shifts from the interface to the bulk: lithium ions find it increasingly difficult to diffuse through the electrode material, while the interfacial reaction kinetics are paradoxically altered in a way that lowers the apparent charge transfer barrier. The authors interpret this as evidence of enhanced diffusion restrictions and altered interfacial kinetics, a signature that over discharge reshapes the interior landscape of the cell rather than merely fouling its surfaces.

One of the most important findings concerns the subtlety of the damage. When the researchers compared spectra taken at equivalent voltages and equivalent cycle numbers, they found that over discharge does not produce dramatic spectral distortion. Instead, it induces progressive shifts in the interfacial resistance and in the low-frequency response of the cell. This is a crucial insight for battery diagnostics, because it means that a catastrophic-looking failure may be preceded by gradual, measurable changes that only careful impedance monitoring would catch. A battery management system that tracks these parameters over time could, in principle, flag a cell that has been over-discharged long before its capacity loss becomes obvious to the user.

The study also examined how these impedance parameters evolve with repeated cycling. Both the charge transfer resistance and the Warburg impedance increased gradually as the cells were cycled, with the tenth cycle exhibiting significantly higher values than the first. This progressive growth suggests cumulative electrode deterioration and a steady loss of ionic transport efficiency. In practical terms, each abuse event, each excursion into the over-discharge zone, leaves a residue of damage that accumulates. The electrodes lose their ability to shuttle lithium ions efficiently, and the battery’s internal resistance climbs, which in turn increases heat generation, reduces power output, and accelerates further degradation in a self-reinforcing loop.

The implications for battery management systems are significant. Modern BMS technology increasingly relies on impedance-based methods to estimate the state of charge and state of health of cells, and a rich body of literature has developed around using EIS for these purposes. Previous studies have shown that impedance measurements can support state-of-charge estimation even for aging batteries, and machine learning approaches have been layered on top of impedance data to improve prediction accuracy. However, most of this work assumes the battery operates within its normal voltage window. The Daegu University study adds a missing piece: a quantitative description of how the key impedance parameters behave when that assumption is violated, which is exactly the situation that occurs in real-world abuse scenarios such as deep discharge during vehicle breakdowns, faulty electronics, or user error.

The findings also connect to a broader research effort on over-discharge failure mechanisms. Earlier work on commercial lithium iron phosphate cells showed that over discharge causes structural and chemical changes in electrodes, including copper dissolution from the anode current collector at extreme depths of discharge, which can lead to internal short circuits. Other studies have documented effects on performance and thermal stability. What distinguishes the new study is its focus on polymer lithium-ion batteries, a format favored for its flexibility and safety, and its systematic separation of the impedance response into interfacial and diffusional components across the full discharge range, including the abusive zone below the normal cutoff voltage.

For consumers, the research underscores a familiar message with new precision: the damage from draining a battery too far is real, measurable, and cumulative. For engineers, it provides a diagnostic roadmap. Because the impedance changes induced by over discharge are systematic rather than chaotic, they can be incorporated into the models that battery management systems use to monitor cell health. A vehicle or device that periodically measures its cells’ impedance could detect the characteristic rise in Warburg impedance and the shifting interfacial resistance that betray a history of deep discharge, then adjust charging strategies or flag the cell for inspection. The authors emphasize that impedance monitoring of this kind is important for early degradation detection and battery management in polymer lithium-ion batteries.

As the world electrifies transportation and deploys ever-larger stationary storage systems, the economics of battery longevity become staggering in scale. Extending the useful life of a battery pack by even a few percentage points translates into enormous savings of cost, raw materials, and environmental impact. Studies like this one, which translate the invisible electrochemistry of degradation into measurable electrical signatures, are the foundation of that effort. The over-discharged battery, it turns out, does tell the story of its abuse; it simply tells it in the language of impedance, at frequencies and magnitudes that only careful spectroscopy can hear. Learning to listen, the Daegu University work suggests, may be one of the most practical steps toward smarter, longer-lived, and safer energy storage.

Subject of Research: Electrochemical impedance analysis of polymer lithium-ion batteries under over-discharge conditions

Article Title: Impedance analysis of polymer lithium-ion batteries under over discharge

Article References: Subedi, M., & Jeong, H. K. (2026). Impedance analysis of polymer lithium-ion batteries under over discharge. Ionics. https://doi.org/10.1007/s11581-026-07501-3

Image Credits: AI Generated

DOI: 10.1007/s11581-026-07501-3

Keywords: lithium-ion battery, over discharge, electrochemical impedance spectroscopy, charge transfer resistance, Warburg impedance, state of charge, battery degradation, polymer battery, battery management system, ionic transport, electrode deterioration, energy storage
