Supercapacitors occupy a peculiar middle ground in the world of energy storage. They cannot match the sheer energy density of lithium-ion batteries, but they can charge and discharge in seconds, tolerate hundreds of thousands of cycles, and deliver bursts of power that would strain most battery chemistries. The challenge that has occupied materials scientists for decades is closing the energy gap without sacrificing the durability that makes supercapacitors attractive in the first place. A new study from a team of Algerian researchers, published in the journal Ionics, reports a deceptively simple route toward that goal: embedding nickel oxide particles directly into electrodeposited polypyrrole films to create a hybrid organic-inorganic electrode with markedly improved performance.
Polypyrrole, often abbreviated PPy, is one of the most tractable conducting polymers in electrochemistry. It can be grown directly onto a conductive surface by simply applying a potential to a solution of pyrrole monomers, a process known as electropolymerization or electrodeposition. The resulting film is electrically conductive, chemically stable, and stores charge through a pseudocapacitive mechanism: as the polymer is oxidized and reduced, ions from the electrolyte move in and out of the film to balance the electronic charge on the polymer backbone. This ion exchange gives polypyrrole a respectable capacitance, but pure polymer films suffer from well-known weaknesses. Their charge storage is limited by the density of accessible redox sites, and the repeated swelling and shrinking that accompanies ion insertion and removal gradually degrades the film, causing capacitance to fade over repeated cycling.
The research team, led by Hanane Khentite of Ferhat Abbas University of Sétif 1 together with colleagues at Mohamed Boudiaf University of M’sila and Mohamed El Bachir El Ibrahimi University of Bordj Bou Arréridj, addressed both weaknesses at once by incorporating nickel oxide, a transition metal oxide with its own rich pseudocapacitive chemistry, into the polymer matrix. Nickel oxide stores charge through reversible surface redox reactions involving the Ni2+/Ni3+ couple, and it is inexpensive, abundant, and environmentally benign compared with many alternative metal oxides such as ruthenium dioxide. The idea of combining metal oxides with conducting polymers is not new, but the details of how the two components are integrated often determine whether the composite outperforms its constituents or merely averages their shortcomings.
The fabrication method was deliberately straightforward. The researchers used indium tin oxide coated glass, a transparent conducting substrate, as the working electrode in an electrochemical cell. By controlling the deposition conditions, they grew a polypyrrole film in which nickel oxide particles were successfully embedded, producing what they designate as the ITO/PPy-NiO electrode. For comparison, they also prepared a pure polypyrrole film on the same substrate under analogous conditions. Electrochemical deposition has a practical advantage over many alternative synthesis routes: the film forms directly on the current collector, eliminating the need for polymer binders and conductive additives that add dead weight and interfacial resistance in conventional slurry-cast electrodes.
Before any electrochemical testing, the team subjected both films to a battery of structural and morphological characterization techniques. Fourier-transform infrared spectroscopy confirmed the chemical signatures of the polymer and the incorporated oxide. X-ray diffraction provided evidence of the crystalline nickel oxide phase within the composite. Scanning electron microscopy and atomic force microscopy revealed how the presence of nickel oxide altered the surface morphology of the films, changes that matter enormously in pseudocapacitive materials because charge storage occurs at or near surfaces where the electrolyte can reach the active material. A rougher, more porous morphology generally means more electrochemically accessible area and therefore higher capacitance.
The electrochemical results were unambiguous. Using cyclic voltammetry at a scan rate of 5 millivolts per second, the composite electrode delivered a specific capacitance of 230.22 farads per gram, while the pure polypyrrole film managed only 150.79 farads per gram under identical conditions. Galvanostatic charge-discharge measurements, which provide a more application-relevant picture of how an electrode behaves under constant current, told a consistent story: the composite achieved 214.87 farads per gram at a current density of 0.3 amperes per gram, against 138 farads per gram for the pristine polymer. In other words, adding nickel oxide boosted capacitance by roughly half, a substantial gain for a relatively modest modification of the synthesis recipe.
Perhaps the most striking result concerns durability, the perennial Achilles heel of conducting polymer electrodes. After 1,000 charge-discharge cycles, the composite electrode retained 89 percent of its initial capacitance, with a Coulombic efficiency above 95 percent, meaning that nearly every unit of charge put into the electrode during each cycle came back out. The pure polypyrrole electrode, by contrast, retained only 50 percent of its capacitance over the same number of cycles. This near-doubling of cycling stability suggests that the nickel oxide particles do more than simply add their own charge storage capacity; they appear to reinforce the polymer mechanically and electrochemically, buffering the volume changes that normally tear polypyrrole films apart during repeated ion insertion and removal.
The galvanostatic measurements also yielded energy and power density figures for the composite: an energy density of 19.1 watt-hours per kilogram at a power density of 120 watts per kilogram. The authors are careful to note that these values were derived from three-electrode measurements and are included for comparative purposes only. This is an important caveat that honest electrochemists increasingly emphasize. Three-electrode data reflect the behavior of a single electrode material in isolation, whereas real devices pair two electrodes in a full cell, and the device-level energy density is inevitably lower than the single-electrode figure suggests. Reporting such numbers with this qualification is a welcome example of restraint in a field where inflated claims have sometimes muddied the literature.
Mechanistically, the improvement can be understood as a synergy between two complementary charge storage mechanisms. The polypyrrole contributes a conductive, ion-permeable network that stores charge through doping and dedoping of its conjugated backbone, while the nickel oxide contributes high-capacity surface redox reactions. The conductive polymer can also serve as an electron highway to oxide particles that would otherwise be poorly connected, and the oxide in turn provides structural anchoring that limits the polymer’s swelling. Similar hybrid strategies have been explored with manganese dioxide, graphene, and other additives, and the present work situates nickel oxide within that broader family of conducting polymer-metal oxide composites that the same research group and others have been developing for years.
The practical implications are modest but real. Electrodeposition is a scalable, low-temperature, solution-based technique compatible with a variety of substrates, and nickel oxide is among the cheapest pseudocapacitive oxides available. An electrode that combines a 50 percent capacitance gain with dramatically improved cycling stability, achieved through a one-step electrochemical route without binders, is exactly the kind of incremental engineering advance that accumulates into commercially meaningful progress. The work, published online on 29 September 2026 in Ionics, adds to a growing body of evidence that the future of supercapacitor electrodes lies not in any single miracle material but in carefully engineered composites where a conductive polymer and a redox-active oxide each compensate for the other’s weaknesses. For grid buffering, regenerative braking, and portable electronics, where devices must deliver power in a flash and survive decades of abuse, that kind of durability-first design philosophy may prove more valuable than any headline-grabbing record.
Subject of Research: Nickel oxide-incorporated polypyrrole composite electrodes for supercapacitor energy storage
Article Title: Increased polypyrrole sheet electrochemical performance for supercapacitor applications by incorporation nickel oxide
Article References: Khentite, H., Habelhames, F., Bahloul, A., Nessark, B., Sayah, A., & Boughezal, A. (2026). Increased polypyrrole sheet electrochemical performance for supercapacitor applications by incorporation nickel oxide. Ionics. https://doi.org/10.1007/s11581-026-07546-4
Image Credits: AI Generated
DOI: 10.1007/s11581-026-07546-4
Keywords: polypyrrole, nickel oxide, supercapacitor, electrochemical deposition, pseudocapacitance, composite electrode, cycling stability, specific capacitance, energy storage, conducting polymer, electrochemistry, Ionics
