Researchers in China have transformed a polysaccharide extracted from the rhizomes of Polygonatum cyrtonema Hua, a plant long valued in traditional food and medicine, into a highly engineered carbon nanomaterial that can detect trace organic pollutants at concentrations as low as one part in ten billion. The study, published in Discover Green Chemistry, describes how a carefully choreographed sequence of chemical modifications converts this natural glycan into carbon dots decorated with silver nanoparticles, producing a surface-enhanced Raman scattering (SERS) substrate that combines remarkable sensitivity with reproducible, stable performance. The work addresses one of the most persistent frustrations in biomass-derived nanomaterials: the difficulty of controlling surface chemistry when the starting material is a complex, variable natural product.
Carbon dots are quasi-zero-dimensional carbon nanomaterials, typically smaller than ten nanometers, that have attracted intense interest for their photoluminescence, ease of surface functionalization, and low toxicity. In recent years, biomass has emerged as a sustainable and cost-effective feedstock for these nanoparticles, offering renewable supply chains and greener synthesis routes compared with synthetic molecular precursors. Yet crude biomass presents a fundamental problem. Composed of mixtures of polysaccharides, proteins, organic acids, and other constituents, it triggers competing reactions during carbonization, yielding structurally heterogeneous products with batch-to-batch variability. That heterogeneity translates into uneven distributions of anchoring sites on the resulting dots, which in turn causes uncontrolled aggregation of metal nanoparticles and poor signal reproducibility in the final SERS substrates.
The research team, led by Chengwei Hu and corresponding author Hong Bi of Anhui University, sidestepped this problem by starting from a structurally well-defined biomacromolecule rather than crude plant matter. Polygonatum cyrtonema Hua polysaccharide, abbreviated PcH, was extracted from dried rhizomes using hot-water extraction followed by ethanol precipitation, deproteinization, decolorization, dialysis, and lyophilization. Mass spectrometric analysis revealed a glucan-type backbone with a regular 162-dalton interval between dominant peaks, corresponding to hexose units, while chromatographic analysis of the acid hydrolysate confirmed glucose as the predominant monosaccharide. The polymer showed a moderately polydisperse population of oligomers with degrees of polymerization of roughly eight to sixteen, and thermogravimetric analysis demonstrated thermal stability up to about 300 degrees Celsius, a property that proved essential for the hydrothermal steps to follow.
The key innovation lies in what the researchers did next. Rather than carbonizing the polysaccharide directly, they first oxidized it selectively with sodium periodate under acidic conditions, converting vicinal diols into dialdehyde functionalities. Quantification using the Schiff reagent method showed the relative oxidation degree jumping from 1.26 percent in the pristine polysaccharide to 96.62 percent in the oxidized product, a near-complete conversion. The dialdehyde intermediate was then condensed with L-lysine, an amino acid whose primary amines react with the aldehyde groups to form imine linkages, the hallmark of Schiff-base chemistry. Nuclear magnetic resonance spectroscopy confirmed the formation of these -C=N- bonds with a characteristic resonance near 8.3 parts per million, while infrared spectroscopy showed the carbonyl band near 1720 wavenumbers weakening as a new band emerged around 1650 to 1680 wavenumbers, consistent with C=N stretching.
These imine motifs are far more than decorative. Nitrogen atoms in imine groups carry lone pairs of electrons embedded in an extended pi-conjugated system, making them excellent coordination sites for metal ions. Crucially, the team demonstrated that these functionalities survive the subsequent hydrothermal carbonization, in which the Schiff-base-functionalized precursor was heated at 160 degrees Celsius for six hours in a sealed autoclave. The resulting carbon dots, termed PcH-CDs, emerged as uniformly dispersed quasi-spherical particles averaging about 2.5 nanometers in diameter, with lattice fringes of roughly 0.20 nanometers corresponding to the (100) plane of graphitic carbon. X-ray diffraction showed the amorphous polysaccharide peak at 22 degrees shifting to 26 degrees after carbonization, indicative of a graphite-like sp2-conjugated framework, while Raman spectroscopy revealed the ratio of disorder to graphitic band intensities dropping from 1.59 to 0.75, signaling increased structural ordering.
With the imine sites preserved on the carbon dot surfaces, the researchers introduced silver through a silver-ammonia complex reduction. The surface-exposed -C=N- groups selectively coordinated silver ions, guiding uniform in-situ nucleation and suppressing the random aggregation that plagues conventional syntheses. Transmission electron microscopy showed the hybrid nanoparticles growing to an average of 13.23 nanometers, with silver nanocrystals of roughly 7 to 10 nanometers estimated from X-ray diffraction line broadening. X-ray photoelectron spectroscopy delivered perhaps the most telling evidence: the silver 3d binding energies in the hybrid were blue-shifted by 0.80 electron volts relative to silver nitrate, a shift attributable to strong coordination between silver and the imine nitrogen, which acts as a stronger electron donor than oxygen and withdraws electron density from the metal center. A control sample prepared from unmodified polysaccharide, lacking these nitrogen sites, showed only minor shifts characteristic of weaker silver-oxygen coordination and exhibited markedly weaker silver diffraction peaks.
The practical payoff came in SERS testing. When Rhodamine B was applied to the PcH-CDs-Ag substrate, the characteristic Raman peak at 1650 wavenumbers remained clearly visible down to a concentration of 1 x 10^-10 molar, with a linear calibration spanning ten^-10 to ten^-6 molar and a correlation coefficient of 0.99. The calculated enhancement factor reached 4.21 x 10^6, roughly three orders of magnitude higher than that of metal-free nitrogen-doped graphene quantum dots for the same analyte. Signal reproducibility, measured across twenty randomly selected points on a single substrate, yielded a relative standard deviation of 11.7 percent, an acceptable figure for practical analytical work. The substrate also proved durable: after six weeks of ambient storage, SERS intensities retained approximately 70 percent of their initial values, with the carbon dot matrix apparently protecting the silver nanoparticles from oxidation. Methylene blue served as a second probe molecule, detectable down to 1 x 10^-8 molar, confirming the platform’s versatility beyond a single analyte.
To understand why the nitrogen-coordinated system outperforms its oxygen-coordinated counterpart, the team turned to density functional theory. Optimized geometries showed an Ag-N bond length of 1.97 angstroms, significantly shorter than the 2.14-angstrom Ag-O bond, indicating a stronger and more localized interaction. Natural bond orbital analysis quantified the difference dramatically: the donor-acceptor interaction from the imine pi bond to the silver acceptor orbital exhibited a second-order stabilization energy of 71.6 kilocalories per mole with an orbital occupation number of 0.39639, whereas the corresponding oxygen-to-silver interaction registered below 3 kilocalories per mole with an occupation number of just 0.01314. The Ag-N system also displayed a substantially narrowed band gap of 1.63 electron volts compared with 3.46 electron volts for Ag-O, conditions that favor excited-state charge transfer across the molecule-metal interface and amplify the chemical enhancement contribution to the SERS signal.
Beyond the immediate analytical performance, the study carries a broader message about how natural polysaccharides can be used in materials design. The authors argue that glycans should be viewed not merely as sustainable carbon sources but as chemically tunable platforms whose repeating-unit backbones and abundant hydroxyl groups allow precise, site-specific molecular modification. By combining regioselective oxidation, Schiff-base condensation, hydrothermal carbonization, and coordination-directed metal deposition, the researchers demonstrated a molecular route to controllable carbon-metal hybrid nanoparticles in which interfacial chemistry, rather than chance, dictates performance. The aqueous processability of the hybrid, along with its uniform silver loading, suggests suitability for coating onto flexible substrates, opening possibilities for lightweight, portable SERS devices for environmental monitoring, food safety testing, and trace detection of organic pollutants. Extending this strategy to other polysaccharide systems, the team suggests, could open new avenues for sustainable materials in advanced sensing applications, turning an ancient medicinal plant into a blueprint for next-generation nanosensors.
Subject of Research: Schiff-base-functionalized carbon dots derived from Polygonatum cyrtonema Hua polysaccharide decorated with silver nanoparticles for surface-enhanced Raman scattering detection of trace organic pollutants
Article Title: Silver decorated Schiff base functionalized carbon dots derived from Polygonatum cyrtonema Hua polysaccharide for surface enhanced Raman scattering
Article References: Hu, C., Zhu, H., Cui, J., Xue, J., Liu, J., Liu, C., & Bi, H. (2026). Silver decorated Schiff base functionalized carbon dots derived from Polygonatum cyrtonema Hua polysaccharide for surface enhanced Raman scattering. Discover Green Chemistry, 1(1), Article 23. https://doi.org/10.1007/s44509-026-00024-0
Image Credits: AI Generated
DOI: 10.1007/s44509-026-00024-0
Keywords: carbon dots, SERS, Polygonatum cyrtonema Hua, polysaccharide, Schiff base, silver nanoparticles, surface-enhanced Raman scattering, biomass, green chemistry, Rhodamine B, density functional theory, nanosensors
