A newly engineered photocatalyst has achieved complete laboratory removal of dithizone from contaminated water in just 21 minutes, dramatically outpacing a conventional zinc oxide material tested under comparable conditions. The result comes from a comparative study of a hybrid nanomaterial built from layered double hydroxide sheets and zinc sulfide quantum dots. The researchers say the system could offer a rapid treatment option for acidic industrial wastewater, where dithizone and related sulfur-containing compounds may persist and interact with toxic metals. The work is also notable because it represents, according to the authors, the first reported attempt to destroy dithizone through photocatalysis rather than simply capture it by adsorption. The findings point toward a broader strategy for water purification: combining materials that concentrate pollutants at a surface with semiconductors that transform light into powerful chemical oxidants.
Dithizone, also known as DTZ, is a sulfur-containing organic ligand used in hydrometallurgy and analytical chemistry because it binds strongly to metal ions. That same chemical behavior can become an environmental liability when the compound enters wastewater. Stable dithizone molecules can remain in aquatic systems, accumulate, and form complexes with metals such as mercury, cadmium, nickel, and copper, potentially changing how those contaminants move through the environment and interact with living organisms. Removing such pollutants is challenging because many conventional treatment methods merely transfer them from water to another material. Adsorption, coagulation, membrane filtration, and related processes can reduce dissolved concentrations, but they may generate concentrated solid waste requiring further disposal. Photocatalytic advanced oxidation takes a different approach. When a semiconductor absorbs sufficiently energetic photons, it produces mobile electrons and positively charged holes. These charge carriers react with oxygen, water, and surface hydroxyl groups to generate reactive oxygen species, including hydroxyl radicals and superoxide, which can attack complex organic molecules and break them into smaller products.
The new catalyst was designed to overcome two familiar weaknesses of standalone semiconductor photocatalysts. Zinc oxide is inexpensive, chemically useful, and has a band gap of roughly 3.3 electron volts, but it rapidly recombines its light-generated electrons and holes. It also absorbs mainly ultraviolet light, which limits its use under ordinary illumination. The researchers instead assembled calcium-magnesium-iron layered double hydroxide, or LDH, with L-cysteine-capped zinc sulfide quantum dots. LDHs are positively charged, sheet-like materials whose composition and interlayer chemistry can be tuned. Their high surface area and adsorption capacity can draw pollutants toward reactive sites. ZnS quantum dots, meanwhile, act as nanoscale light absorbers. Placing the two components in intimate contact creates a heterojunction, an interface where charge carriers may be spatially separated rather than immediately annihilating one another. The researchers propose that electrons move preferentially toward the LDH side while holes remain associated with the semiconductor, extending the lifetime of both and increasing the production of oxidative species.
The synthesis involved several carefully controlled steps. The CaMgFe LDH was produced by adding alkaline solution to metal nitrate precursors while holding the mixture near pH 10, then aging and drying the precipitated layered material. Zinc sulfide quantum dots were formed in water from zinc nitrate and sodium sulfide, with L-cysteine acting as a capping molecule to limit uncontrolled growth and aggregation. The quantum dots were deposited directly onto dispersed LDH through an in situ process. X-ray diffraction confirmed that the hybrid contained both the hydrotalcite-like LDH phase and cubic zinc-blende ZnS, without detectable impurity phases. Electron microscopy showed plate-like LDH sheets covered by small, dark ZnS particles measuring approximately 5–8 nanometers. The composite particles averaged about 110 nanometers, while the pristine LDH averaged about 53 nanometers. Elemental analysis detected magnesium, calcium, iron, zinc, sulfur, oxygen, carbon, and nitrogen, supporting the presence of both the inorganic components and the cysteine-derived surface chemistry.
For a direct benchmark, the team also prepared flower-like ZnO nanostructures using a hydrothermal reaction followed by calcination. Microscopy revealed three-dimensional architectures made of interconnected nanopetals, a shape that can provide accessible surfaces and multiple paths for scattering light through the material. The two catalysts behaved very differently under optimized ultraviolet experiments. In a typical test, 10 milligrams of LDH@ZnS was dispersed in 25 milliliters of dithizone solution containing 10 milligrams per liter of pollutant. At pH 3, the hybrid removed 100 percent of the dithizone signal in 21 minutes, with more than 83 percent disappearing during the first nine minutes. The characteristic ultraviolet-visible absorption peak at 595 nanometers vanished, indicating destruction of the molecule’s chromophore. By comparison, flower-like ZnO required about 60 minutes to exceed 94 percent removal under its optimal mildly acidic condition of pH 5. The researchers emphasize that the disappearance of the optical signal demonstrates decolorization or depletion of the measured dithizone, but not definitive mineralization; total organic carbon analysis was not performed.
The unusual speed of the LDH-based material appears to arise from several effects operating simultaneously. At acidic pH, the catalyst surface becomes positively charged, while ionized dithizone species are attracted to it. This electrostatic pre-concentration places pollutant molecules close to the light-generated reactive sites before irradiation even begins. The LDH also provides a structured support that helps keep the quantum dots dispersed, preventing them from clumping into less active masses. Under illumination, ZnS produces electrons in its conduction band and holes in its valence band. Electrons can reduce dissolved oxygen to superoxide radicals, while holes oxidize water or surface hydroxyl groups to form hydroxyl radicals. These species then attack adsorbed dithizone, with the researchers suggesting that sulfur- and azo-related portions of the molecule may be among the initial targets. The proposed pathway could ultimately produce carbon dioxide, water, sulfate, nitrate, and other inorganic products, but identifying intermediates and measuring mineralization will require follow-up analyses such as liquid chromatography–mass spectrometry and total organic carbon measurements.
The catalyst’s performance was sensitive to the chemistry and physical conditions of the treatment. Increasing dithizone concentration from 5 to 50 milligrams per liter reduced the percentage removed, likely because the catalyst surface became saturated and the pollutant absorbed more of the incoming light before it reached the photocatalyst. More catalyst was not always better either. LDH@ZnS performed best at 10 milligrams per 25 milliliters; higher amounts made the suspension turbid, increasing light scattering and shielding. ZnO reached its optimum at 15 milligrams under the tested conditions. The LDH@ZnS hybrid remained highly effective under ultraviolet, visible, tungsten-lamp, and blue-LED illumination, although its magnetic version performed less strongly under visible-rich light and sunlight. The unmodified hybrid reached near-complete removal across the tested sources in the short comparison window, while ZnO achieved complete removal under blue LED and sunlight only after longer irradiation, around 90 minutes. These results suggest a trade-off between rapid treatment under energetic light and slower but potentially more practical solar operation.
To make recovery easier, the researchers built a magnetic analogue by placing the photocatalytic layers around an iron oxide core coated with silica and an aminosilane layer. The final magnetic composite had a saturation magnetization of 3.17 electromagnetic units per gram, far below the 66.77 of the original magnetite because the nonmagnetic coatings and ZnS increased the total mass. Even so, the particles could be rapidly pulled from water with a permanent magnet and redispersed afterward. The magnetic version still achieved complete dithizone removal in 21 minutes under ultraviolet light, although its early reaction rate was slower than that of the nonmagnetic hybrid. Reuse tests showed that LDH@ZnS retained more than 90 percent activity through three cycles, with a noticeable decline beginning in the fourth. The magnetic catalyst showed no detectable release of the tested metal ions, suggesting stability under the experimental conditions. ZnO was even more durable in repeated testing, retaining more than 94 percent of its initial efficiency after five cycles.
The experiments also reveal where the technology may struggle outside the laboratory. Low concentrations of common salts caused little inhibition, but salt levels near 2,000 milligrams per liter reduced performance for both catalysts. Bromide and iodide can consume photogenerated holes and hydroxyl radicals, while competing anions can occupy the positively charged adsorption sites needed to capture dithizone. High ionic strength may also compress the electrical double layer surrounding particles, encouraging aggregation and hindering transport through the water. Other organic contaminants had contrasting effects. Naphthalene, 4-nitrophenol, and acyclovir competed with dithizone for sites and consumed nonspecific hydroxyl radicals on the LDH@ZnS surface, reducing its target-specific efficiency. ZnO, by contrast, showed greater resilience in mixtures, with several compounds degrading at similar rates even when present together. The researchers therefore envision different applications for the two materials: LDH@ZnS for fast treatment of acidic streams where dithizone is the main target, and flower-like ZnO for mixed-pollutant or sunlight-driven treatment where longer reaction times are acceptable. The promising laboratory results are an important step, but real wastewater trials, toxicity tests on breakdown products, continuous-flow studies, and direct mineralization measurements will be needed before either catalyst can be considered ready for industrial deployment.
Subject of Research: Photocatalytic degradation of dithizone in water using LDH@ZnS quantum-dot nanocomposites and flower-like ZnO nanostructures.
Subject of Research: Chemistry
Article Title: Enhanced photocatalytic degradation of dithizone using LDH@ZnS quantum dots and flower-like ZnO nanostructures: a comparative study
Article References: Qarache, M. A., Rajabi, H. R., Koraei, S., & Khani, O. (2026). Enhanced photocatalytic degradation of dithizone using LDH@ZnS quantum dots and flower-like ZnO nanostructures: a comparative study. Results in Chemistry, 29, Article 103760. https://doi.org/10.1016/j.rechem.2026.103760
Image Credits: AI Generated
DOI: 10.1016/j.rechem.2026.103760
Keywords: dithizone degradation, photocatalysis, zinc sulfide quantum dots, layered double hydroxide, zinc oxide nanoflowers, wastewater treatment, reactive oxygen species, magnetic catalyst
