A simple ingredient found in food, cosmetics and pharmaceuticals could help turn a familiar water-soluble plastic into a flexible, biodegradable material that also slows the movement of heat. In a study published in the Journal of Materials Science, researchers report that adding glycerol to polyvinyl alcohol, or PVA, substantially reduces the polymer’s thermal diffusivity while increasing its flexibility, water solubility and biodegradability. The most heavily plasticised film showed a 33.41 percent lower thermal diffusivity than pristine PVA, suggesting that the material could serve as a lightweight thermal-insulating substrate for next-generation flexible electronics.
The result is striking because PVA already occupies an unusual position among synthetic polymers. It can form transparent, strong films and is widely investigated for packaging, sensors, biomedical materials and electronic devices. Unlike many conventional plastics, PVA can dissolve in water and is capable of biological degradation under suitable environmental conditions. Yet unmodified PVA is relatively stiff, and its molecular structure can allow heat to move through the material more efficiently than would be ideal for electronics designed to bend, stretch or operate close to the skin. The new study focuses on whether glycerol can simultaneously soften the polymer and reshape the pathways through which thermal energy travels.
Glycerol acts as a plasticiser, a small molecule that enters the spaces between long polymer chains and changes how those chains interact. PVA consists of repeated units containing hydroxyl groups, or –OH groups, attached to a carbon-based backbone. These groups form hydrogen bonds both within and between chains, helping give PVA its mechanical strength and partial crystallinity. When glycerol is incorporated, its own hydroxyl groups participate in this hydrogen-bonding network. Rather than simply filling empty space, glycerol changes the balance of molecular attractions, increases chain mobility and disrupts some of the ordered arrangements that otherwise help transmit vibrational energy through the film.
The researchers measured the films’ thermal diffusivity using laser-induced photoacoustic spectroscopy in a transmission configuration. Thermal diffusivity describes how quickly a temperature disturbance spreads through a material and is commonly expressed as the ratio of thermal conductivity to the product of density and heat capacity. A material with lower thermal diffusivity takes longer to equilibrate after being heated locally, making it more effective at limiting rapid heat propagation. In the photoacoustic approach, a modulated laser beam periodically heats the sample. The resulting expansion and contraction generates pressure waves that can be detected acoustically. Because the amplitude and phase of the signal depend on how heat diffuses through the specimen, the technique allows thermal transport to be inferred without relying solely on direct temperature measurements.
Across the glycerol-containing films, thermal diffusivity declined progressively as the plasticiser content increased. The trend indicates that glycerol does not merely soften PVA mechanically; it also alters the structure responsible for heat transport. In polymeric materials, thermal energy is carried largely through collective molecular vibrations often described as phonons. Unlike electrons in a metal, these vibrations do not travel through a perfectly ordered lattice in an ordinary polymer. Their movement is already interrupted by chain disorder, defects, interfaces and molecular motion. Additional disruption from glycerol can shorten the distance over which vibrational energy travels before being scattered, reducing the rate at which heat spreads.
Spectroscopic measurements provided clues to the molecular origin of that change. Fourier-transform infrared spectroscopy and Raman spectroscopy detected stronger interactions involving hydroxyl groups after glycerol was added. Those interactions disrupted intermolecular methylene-related arrangements within the PVA matrix, according to the researchers, creating a less continuous route for vibrational energy. The distinction matters: the film’s lower thermal diffusivity is not explained simply by the presence of a low-conductivity additive. It reflects a reorganisation of the polymer network at the molecular scale, in which glycerol modifies hydrogen bonding and makes the chains more mobile and less efficiently packed.
X-ray diffraction offered a second line of evidence. The crystallinity of pure PVA was measured at 47.02 percent, but it fell to 24.96 percent in the highly plasticised film. Crystalline regions contain chains arranged in comparatively regular patterns, while amorphous regions are more disordered. Heat can move differently through these two domains, and the boundaries between them scatter vibrational carriers. By reducing the fraction of ordered material and increasing the amorphous content, glycerol appears to make the film more structurally heterogeneous and less favourable to rapid thermal transport. The finding links the macroscopic insulation effect directly to a measurable change in PVA’s internal organisation.
That structural transformation came with a familiar materials-science trade-off. Thermogravimetric analysis showed that thermal stability decreased as glycerol loading increased, consistent with the greater chain mobility introduced by plasticisation. A polymer whose chains can move more freely may bend without cracking, but it can also begin to soften or decompose at lower temperatures. The researchers therefore do not present glycerol-rich PVA as a universal replacement for heat-resistant engineering plastics. Instead, the material may be best suited to applications in which flexibility, low-temperature processing, biodegradability and thermal damping are more important than prolonged exposure to high operating temperatures.
Mechanical testing showed that the films’ Young’s modulus declined with glycerol incorporation. Young’s modulus measures a material’s resistance to elastic deformation: a lower value generally means that less force is required to bend or stretch it. This reduction produced films with improved flexibility, bringing their mechanical behaviour closer to that of conventional flexible materials while retaining PVA’s environmental advantages. At the same time, the altered surface morphology and microstructure observed with field-emission scanning electron microscopy showed that glycerol changes more than the bulk chemistry. The film surfaces evolved visibly as the plasticiser was added, evidence of a broader reorganisation during film formation.
The environmental profile of the films also shifted in the desired direction for short-lived products and disposable components. Increasing glycerol content enhanced both soil biodegradability and water solubility. These properties could be valuable for materials intended to break down after use or dissolve under controlled conditions, although they could also complicate applications that require resistance to humidity, rain or accidental contact with water. The study does not establish how rapidly the films would degrade in every environment, nor does it demonstrate performance in a finished electronic device. Those questions will be essential before the material can move beyond laboratory-scale films.
The possible electronics applications arise from the unusual combination of properties rather than from insulation alone. Flexible electronics use thin substrates that support conductive traces, sensors, displays or energy-harvesting elements while tolerating bending. A biodegradable PVA-glycerol substrate could reduce the persistence of temporary devices, wearable sensors or environmentally disposable electronics. Its reduced thermal diffusivity might also help limit heat transfer between a device and its surroundings, or moderate local temperature changes in thin-film architectures. But the material’s water sensitivity and lower thermal stability mean that future designs may require protective coatings, cross-linking or multilayer structures to control dissolution without sacrificing biodegradability.
The photoacoustic method could become as important as the specific film formulation. Thermal transport in thin, soft and partially transparent materials can be difficult to measure using conventional techniques, which often require a well-defined temperature gradient or physical contact with the sample. Laser-induced photoacoustic spectroscopy can probe how a periodic heat wave travels through a film and is sensitive to changes in thermal diffusivity caused by composition and morphology. By pairing that measurement with infrared and Raman spectroscopy, diffraction, microscopy, thermogravimetry and mechanical testing, the researchers created a chain of evidence connecting glycerol concentration to molecular bonding, crystallinity, heat flow and flexibility.
The work was carried out by V. S. Sreelakshmi, M. S. Swapna and S. Sankararaman of the Department of Optoelectronics at the University of Kerala in India. The authors describe glycerol-plasticised PVA as a promising sustainable, biodegradable, flexible and thermally insulating material for eco-friendly electronic substrates. The study’s most immediate message is that the same molecular disorder that softens a polymer can also impede heat transport. By tuning the amount of glycerol, designers may be able to balance flexibility and insulation against stability and water resistance. That balance could determine whether an ordinary polymer film becomes a practical component in a new generation of electronics designed not only to bend, but eventually to disappear.
Subject of Research: Glycerol-plasticised polyvinyl alcohol films and their thermal, structural, mechanical and environmental properties
Subject of Research: Technology and Engineering
Article Title: Effect of glycerol plasticisation on the thermal diffusivity of Polyvinyl alcohol (PVA) films: A photoacoustic study
Article References: Sreelakshmi, V. S., Swapna, M. S., & Sankararaman, S. (2026). Effect of glycerol plasticisation on the thermal diffusivity of Polyvinyl alcohol (PVA) films: A photoacoustic study. Journal of Materials Science. https://doi.org/10.1007/s10853-026-13632-9
Image Credits: AI Generated
DOI: 10.1007/s10853-026-13632-9
Keywords: polyvinyl alcohol, glycerol plasticisation, thermal diffusivity, photoacoustic spectroscopy, flexible electronics, biodegradable films, thermal insulation, polymer crystallinity
