A smartphone-style photograph of a maize seed could soon reveal far more than its color and shape. Researchers have developed an artificial-intelligence system that uses ordinary red, green and blue images to identify seeds most likely to produce strong seedlings, offering a potentially inexpensive alternative to laboratory vigor tests that can take days and destroy the seeds being examined. In greenhouse trials, maize seeds selected by the system produced emergence rates 18 to 22 percentage points higher than those of unselected seeds, even when the seeds had been stored for as long as three years. The approach, described by its developers as SeedFocusNet, does not attempt to determine every aspect of seed quality. Instead, it is designed around a narrower and more practical question: which seeds can be trusted as high-vigor candidates for planting?
Seed vigor is more demanding than germination. A basic germination test may record whether a seed eventually produces a radicle, the embryonic root that breaks through the seed coat. Vigor also captures how rapidly and uniformly that process occurs and whether the resulting seedling develops strongly enough to establish itself. These distinctions matter in agriculture because slow or weakly emerging plants can leave gaps in a field, compete poorly with weeds and contribute to uneven yields. Conventional vigor assessments, including tetrazolium staining, can require several days of skilled labor and often involve cutting, staining or otherwise sacrificing the seed. Such procedures are difficult to scale when breeding programs or commercial seed operations must screen thousands or millions of individual seeds before sowing.
More sophisticated imaging technologies have already demonstrated that seed quality can be detected without destruction. X-ray computed tomography can map internal structures, while hyperspectral and near-infrared cameras capture optical signatures associated with chemical composition, moisture and tissue condition. Under controlled conditions, these methods have achieved very high classification accuracy for several crop species. Their weakness is practical rather than scientific: the instruments are expensive, technically demanding and often unsuitable for routine screening outside specialized facilities. RGB cameras, by contrast, are widely available and relatively inexpensive. Yet they record only reflected visible light. A seed may appear healthy on the outside while harboring physiological damage, depleted reserves or impaired tissues that cannot be seen directly. The challenge for the researchers was therefore to extract weak, indirect clues from images without pretending that surface appearance provides a complete biological diagnosis.
The team began with 955 maize seeds from a germplasm repository in China. The seeds had been stored at 4 degrees Celsius for three years, providing a naturally aged population rather than an artificially damaged sample. Each seed was photographed individually using a high-resolution RGB camera and weighed to the nearest 0.001 gram. The seeds were then placed in a 96-well germination tray, soaked for one hour and incubated at 30 degrees Celsius under a 16-hour light and eight-hour dark cycle. Researchers recorded images and weights after 24, 48 and 72 hours. By the third day, professional assessors classified a seed as high vigor only if it had absorbed enough water, produced an acceptable radicle and developed the plumule, the embryonic shoot. The water-uptake requirement was defined mathematically as a weight increase of at least 45 percent relative to the starting mass. Of the total sample, 530 seeds, or 55.5 percent, met all three conditions.
The germination measurements revealed why a photograph taken before sowing might be difficult to interpret. High- and low-vigor seeds began with almost identical average weights of roughly 0.45 grams, and their external areas and dimensions overlapped extensively. During the first two days, their weight trajectories were also similar. By day three, however, the average mass of high-vigor seeds had risen to 0.83 grams, compared with 0.69 grams for low-vigor seeds. That difference reflected a chain of internal biological events: water entering the seed reactivates metabolism, enzymes begin mobilizing stored starches and proteins, and the embryo resumes growth. The researchers found that static morphological measurements alone were poor predictors. Conventional machine-learning models using 12 shape-related features and initial weight achieved accuracies between 51.3 and 61.2 percent, little better than would be expected from a difficult visual classification problem.
SeedFocusNet addresses this limitation by concentrating on small regions of the seed image that may contain more useful information than the entire surface. First, the raw image is converted into the HSV color space, separating brightness from hue and saturation. Histogram equalization is applied only to the brightness channel, reducing uneven illumination without distorting the seed’s colors. Otsu thresholding then separates the seed from its background, while a 7-by-7 morphological filter removes small artifacts and breaks unwanted connections. The largest connected region is retained as the seed mask, producing a background-free image. The system subsequently identifies the micropylar and chalazal ends, the hilum region and areas associated with surface damage. These regions of interest, along with the original seed image, are resized to 224 by 224 pixels and combined into a 15-channel representation rather than the usual three RGB channels.
That expanded input is processed by a shallow, two-layer convolutional network before reaching a deeper image-classification backbone. The first convolution uses 32 filters with 3-by-3 kernels, followed by batch normalization, a nonlinear rectified-linear-unit activation and max pooling. A second convolution with 1-by-1 kernels fuses information across channels and compresses the 15-channel input into three feature maps. A dropout rate of 0.25 is used during training to reduce overfitting. The resulting representation is then passed to one of six established architectures: ResNet18, ResNet50, ResNet101, EfficientNet, InceptionV3 or a vision transformer. This combination is intended to preserve localized clues while keeping the computational burden manageable. It also reflects a biological reality: if vigor-related signals are faint, the model may benefit more from selecting informative regions than from simply adding depth or width to the network.
The researchers also changed how the model was trained. Because their operational priority was to avoid labeling weak seeds as high vigor, they used Focal Loss instead of ordinary cross-entropy loss. Focal Loss reduces the contribution of easy, high-confidence examples and emphasizes samples that are difficult to classify. Its key parameters, alpha and gamma, control class weighting and the strength of this emphasis. The model’s training process used Bayesian optimization through the Optuna framework to search for suitable alpha, gamma and learning-rate values over 500 trials. Rather than maximizing accuracy alone, the researchers created a score that rewards a large number of correctly identified high-vigor seeds only when precision exceeds the underlying proportion of high-vigor seeds. This design explicitly balances coverage against false positives, a crucial trade-off in screening. The data were divided at the seed level into training, validation and test sets in a 7:1:2 ratio, ensuring that images and measurements from one seed could not leak into multiple groups.
Among the tested backbones, ResNet50 provided the strongest overall compromise. At the operating point that maximized the custom score, it achieved 74.4 percent precision and 54.5 percent recall for high-vigor seeds, correctly identifying 61 high-vigor seeds among 82 that it labeled as high vigor. Precision indicates how many selected seeds were genuinely high vigor; recall indicates how many of all high-vigor seeds were successfully captured. The model could be made more conservative: under a precision-focused setting, it reached 85.3 percent precision, but recall fell to 25.9 percent. ResNet18 produced the highest recall, identifying 75 true high-vigor seeds with 70.1 percent precision, while InceptionV3 reached 84.2 percent precision but captured far fewer positives. In comparison, an optimized ResNet50 baseline using standard cross-entropy achieved 67.5 percent precision and 46.4 percent recall. Removing the region-of-interest or shallow-fusion components also reduced performance, suggesting that the added processing contributed to the gains rather than merely increasing model complexity.
The decisive test came in a greenhouse rather than on a computer. For seeds stored for one, two and three years, the researchers compared 50 SeedFocusNet-selected seeds with 50 seeds drawn from the original unselected batches. After seven days in sand culture, 39 of the selected one-year seeds had emerged, compared with 30 controls, raising emergence from 60 to 78 percent. In the two-year group, emergence increased from 54 to 76 percent, while three-year seeds improved from 48 to 68 percent. These are encouraging results because emergence is closer to the agricultural outcome that growers care about than a classification score alone. However, the system remains a laboratory proof of concept, not a universal seed-quality test. The dataset came from one maize accession and one genetic background, and all images were taken with fixed lighting and camera settings. Performance under different cultivars, storage histories, field conditions and industrial sorting lines remains unknown. Repeated data splits, external validation and explainability studies will be needed to determine whether the network has learned general physiological signals or merely visual features specific to this seed population. Even with those caveats, the work points toward a striking possibility: inexpensive cameras paired with carefully designed machine learning could help turn seed selection from a slow destructive assay into a rapid, non-destructive first pass.
Subject of Research: RGB-image-based deep-learning prediction and screening of high-vigor maize seeds
Article Title: SeedFocusNet: RGB image-based prediction of maize seed vigor using deep learning, focal loss and Bayesian optimization
Article References: Liu et al., study on SeedFocusNet and RGB-based maize seed-vigor screening; original research link not provided
Image Credits: AI Generated
DOI: Not provided
Keywords: maize seed vigor, seed screening, RGB imaging, deep learning, SeedFocusNet, computer vision, Focal Loss, Bayesian optimization, greenhouse emergence
