Cell culture media trigger volume-dependent acoustic effects in QCM sensors

A laboratory study found that two media commonly used to culture breast cancer cells can make quartz crystal microbalance sensors oscillate strongly, even when no cells are present. Droplets of Dulbecco’s Modified Eagle Medium and Roswell Park Memorial Institute 1640 medium produced periodic changes in both the sensor’s resonance frequency and its electrical resistance. The patterns depended strongly on droplet volume and were more pronounced at larger volumes. The observations indicate that part of a QCM signal attributed to biological material may instead arise from compressional acoustic waves reflecting inside the liquid. Establishing this cell-free baseline is essential if the technology is to distinguish medium effects from changes associated with breast cancer cells.

The experiments used a 5 MHz AT-cut quartz crystal with a 13 mm active gold electrode in a QCM200 measurement system. The researchers loaded the central sensing surface with 400, 600, 800 microlitres or 1 millilitre of complete DMEM or complete RPMI-1640. Both media were prepared as sterile 1X solutions and supplemented with 10% fetal bovine serum and 1% penicillin-streptomycin. Each condition was tested in three independent runs, with frequency and resistance recorded continuously for 120 minutes at intervals of 1.02 seconds. Measurements were conducted at approximately 25 degrees Celsius in an open chamber, and the crystal was allowed to settle for about one minute after loading.

The sensitivity comes from the fact that a quartz resonator measures more than added mass. Its oscillation interacts with the surrounding liquid, and the resulting electrical signals reflect both interfacial loading and energy dissipation. Classical QCM analysis treats the liquid primarily as a semi-infinite Newtonian medium into which the crystal launches shear waves. That simplified picture can omit longitudinal motion at the crystal surface and the compressional waves it creates. In a finite droplet, those waves travel through the liquid, reflect from the upper liquid-air boundary and return to the sensor, creating an acoustic cavity whose interference condition changes the effective load applied to the resonator.

The study describes this cavity with a Fabry–Perot-type model. Compressional-wave impedance depends on the liquid’s P-wave modulus, sound speed, density and wavenumber, together with the thickness of the liquid layer and the acoustic reflectivity of its boundaries. A phase factor determines how the returning wave changes the load, while the time for the liquid interface to shift by half a wavelength helps characterize the evolution of the impedance. The frequency and resistance channels respond through different physical pathways: frequency is tied more closely to the effective mass-loading response, whereas resistance reflects dissipation. Their oscillations can therefore differ in both phase and amplitude even when they are driven by the same changing acoustic condition.

Four temporal parameters were extracted from the time-resolved traces. The first was the characteristic period of the compressional-wave-induced modulation, which describes how rapidly the QCM response changes rather than how long a megahertz longitudinal wave takes to cross the liquid. The second and third were the peak-to-peak amplitudes of the frequency and resistance oscillations, measuring the total excursion of the apparent mass-loading and dissipative signals. The fourth quantified the time offset by which the resistance oscillation led the frequency oscillation. This phase difference provided evidence that the two electrical observables were responding differently as the acoustic interference condition evolved.

DMEM showed a clear transition with increasing volume. At 400 microlitres, the frequency and resistance traces remained comparatively smooth and slowly oscillating, alongside a continuous decrease in frequency. At 600 microlitres, the oscillations became more stable and exhibited little drift. At 800 microlitres and 1 millilitre, the records developed more irregular, higher-frequency fluctuations. Across the media, the characteristic modulation period shortened from approximately 40 minutes at the lower volumes to approximately 5 minutes as the volume increased. The period was more reproducible than the modulation amplitudes, which showed greater variability across repeated measurements.

RPMI-1640 followed the same broad volume-dependent pattern but developed high-frequency fluctuations at a lower loading: they were already noticeable at 600 microlitres. At 1 millilitre, its traces became strongly irregular, with substantial fluctuations throughout the 120-minute recording. Water provided a useful comparison because it displayed the most pronounced compressional-wave behaviour. Its frequency and resistance modulation amplitudes were consistently the largest, while its characteristic periods were the shortest. High-frequency fluctuations were visible in water at 800 microlitres. These comparisons show that neither liquid volume nor medium composition can be considered in isolation: the acoustic response emerged from their combined influence on wave reflection, attenuation and cavity geometry.

Increasing the volume does not necessarily enlarge the relevant acoustic path in direct proportion to the added liquid. Additional fluid can spread laterally across the sensor as well as deepen the layer above the active region. The experimental volume series establishes the overall trend, but the authors did not independently measure cavity thickness or acoustic path length for every loading condition. Their model explains how a changing phase factor can alter compressional-wave impedance, whereas the experiments associate that effect with droplet volume. A fully quantitative mapping between dispensed volume and cavity thickness would require separate geometric and acoustic characterization, which the study did not perform.

Several other limitations constrain how the results should be interpreted. The repeated runs were used to describe variability rather than to establish statistical significance because no formal hypothesis test was conducted. Ambient pressure and relative humidity were not independently monitored, although the large droplets produced no significant visible evaporation during the measurements. The experiments were performed outside a biological safety cabinet in an open measurement chamber, and the results concerned complete media at room temperature on one type of 5 MHz sensor. The work therefore establishes a baseline under the stated conditions rather than a universal correction rule for every QCM geometry, medium formulation or biological assay. The reported standard deviation and mean values also should not be mistaken for evidence of a formal group difference.

For researchers using QCMs to study breast cancer cell adhesion, growth or other cellular dynamics, the practical implication is that medium-only measurements should be collected under the same loading and timing conditions as cell-containing experiments. A frequency shift or resistance change should not automatically be assigned to cells when the liquid itself supports cavity-mediated compressional-wave modulation. The study’s next stage is to incorporate the identified medium response as a baseline correction in experiments involving breast cancer cells. That step could improve the interpretation of mass-loading and viscoelastic signals, although the present research did not test cells, demonstrate improved diagnostic performance or establish a clinical benefit.

Subject of Research: Compressional acoustic-wave effects in QCM measurements of breast cancer cell culture media

Article Title: Analysis of compressional acoustic wave responses in cell culture media for reliable QCM-based breast cancer cell monitoring

Article References: Kannan, H., Babu, R. P., Ghosh, T., Mohapatra, A., Dutta, M., & Ganesan, A. (2026). Analysis of compressional acoustic wave responses in cell culture media for reliable QCM-based breast cancer cell monitoring. Frontiers in Sensors, 7, Article 1949532. https://doi.org/10.3389/fsens.2026.1949532

Image Credits: AI Generated

DOI: 10.3389/fsens.2026.1949532

Keywords: quartz crystal microbalance, breast cancer cells, cell culture media, compressional acoustic waves, biosensors, DMEM, RPMI-1640, acoustic cavity, mass loading, liquid-phase sensing, Analysis, compressional
