Respiratory infections and air pollution are often monitored with instruments that depend on pumps, batteries, tubing, and laboratory infrastructure. Those requirements can make airborne sampling expensive, difficult to miniaturize, and impractical in remote or resource-limited settings. Researchers at the Technical Institute of Physics and Chemistry of the Chinese Academy of Sciences have now developed a radically different approach: an air-sampling device that uses the rupture of a liquid film to move captured material through microscopic channels, eliminating the need for a mechanical pump or an external power supply. Inspired by the feeding mechanism of butterflies, the technology could provide a low-cost way to collect and concentrate airborne pollutants and biological material close to its source.
The system, called Film-Rupture Actuated Capillary Enrichment, or FACE, is designed to combine sampling, recovery, enrichment, and delivery to a detection zone in one compact device. According to the researchers, each disposable unit can cost as little as $0.12. The work, reported in the Proceedings of the National Academy of Sciences, addresses a longstanding challenge in aerosol analysis: airborne targets are usually present at very low concentrations, while conventional samplers can lose material during transport through tubing, recovery from collection surfaces, and dilution before testing. FACE instead uses surface tension and capillary transport to move the collected sample directly into a region where it can be analyzed.
The biological inspiration came from the proboscis of a butterfly, the long, flexible feeding structure that allows the insect to drink nectar. Although the proboscis resembles a narrow straw, its internal fluid-transport mechanism is more complex than simple suction. Using X-ray imaging, the researchers observed that a coiled proboscis can retain a thin liquid film within its structure. As feeding proceeds, the film becomes progressively thinner until it reaches a critical condition and ruptures. The rupture releases the surface energy stored in the film, rapidly propelling the remaining liquid into the feeding passage. Because the process is driven by the physics of liquid interfaces rather than by muscular motion, it occurs in milliseconds and requires virtually no energy input.
The FACE device reproduces this principle in a miniature, 3D-printed structure roughly the size of a coin. At its center is a ring-shaped liquid film connected to narrow capillary channels. During sampling, the exposed film acts as a collection interface. Airborne materials, including pollutant gases, pesticide residues, particles, and droplets containing biological molecules, can become incorporated into or captured by the liquid. The device does not actively draw air in the way a pump-driven sampler does; instead, its geometry and exposed liquid surface allow targets moving through the surrounding air to be collected over time. This passive configuration makes the sampler lightweight and suitable for applications in which adding a battery or motor would be impractical.
After the sampling period, a test strip or detection substrate is brought into contact with the device. That contact initiates rupture of the liquid film. The sudden change in the liquid interface produces a pressure and flow response that drives the collected fluid through the capillary network. Capillary forces then guide the liquid toward the detection area, carrying the material captured during sampling with it. In effect, the film serves first as an airborne collection layer and later as a triggerable microfluidic actuator. The same liquid that gathers the targets also transports them, reducing the number of transfer steps that commonly cause losses in aerosol analysis. The researchers describe this integrated process as a pump-free route to capillary enrichment.
A central test of any passive sampler is whether it can function when air is moving rapidly around it. The team reports that FACE remained effective under strong airflow, a feature that could make it useful on agricultural drones. Mounted on an unmanned aerial vehicle, the device could collect airborne pesticide residues above crop fields without requiring the drone to carry additional pumping equipment or substantial power-consuming analytical hardware. Such measurements could help assess the movement of pesticide aerosols and provide information relevant to field safety and environmental exposure. Because the sampler is disposable and inexpensive, it may also allow repeated measurements across different locations rather than relying on a single costly instrument.
The researchers also investigated the platform for near-source monitoring of respiratory bioaerosols. Exhaled particles and droplets can contain viral proteins or other biological markers, but they become increasingly diluted as they disperse into the surrounding air. A small sampler positioned near the mouth and nose could collect material before that dilution becomes substantial, potentially improving the efficiency of testing. In experiments involving the SARS-CoV-2 nucleocapsid protein, the FACE platform reportedly achieved detection sensitivity 100 times higher than conventional pump-based aerosol samplers. This result concerns detection of the viral nucleocapsid target and should not be interpreted as proof that the device independently identifies infectious virus. Nevertheless, the finding suggests that near-source collection and direct enrichment may significantly improve the analytical signal available for respiratory surveillance.
The reported performance also reflects a difference in how the technology handles sample volume. Traditional aerosol systems often move air through long tubes into a separate liquid or filter collector. Material can adhere to the tubing, remain trapped during recovery, or become diluted when the collector is processed. FACE keeps the collection interface close to the detection pathway and avoids many of these intermediate stages. In the researchers’ experiments, collection and recovery efficiencies approached 100 percent, while the overall dilution ratio was reported as 1.14. A low dilution ratio is particularly important when the target is scarce, because excessive dilution can reduce the concentration below the threshold of a rapid assay even when the original air sample contains a detectable signal.
The broader significance of FACE lies in its use of a controlled physical event in place of an electromechanical pump. Pump-based systems remain valuable for standardized environmental and clinical measurements, but they can be heavy, costly, noisy, and dependent on regular charging or maintenance. By contrast, a film-rupture actuator can be fabricated from inexpensive materials and stored until needed, with the sampling process requiring no battery or external power. The researchers envision applications in respiratory disease screening, environmental monitoring, agricultural safety, and public-health surveillance, particularly in areas where laboratory equipment and electricity are limited. Before the technology can support routine viral monitoring, however, further work will be needed to evaluate its performance across different pathogens, humidity levels, airflow conditions, sampling durations, and real-world aerosol mixtures. Even with those questions remaining, a mechanism first revealed inside a butterfly’s proboscis has provided researchers with a promising blueprint for compact airborne sampling and virus-related surveillance.
Subject of Research: Not applicable
Article Title: Film-rupture actuated pump-free capillary enrichment for near-source airborne sampling
Web References: https://doi.org/10.1073/pnas.2615727123
References: Proceedings of the National Academy of Sciences, DOI: 10.1073/pnas.2615727123
Image Credits: DONG’s group
