Arsenic in the groundwater of Bangladesh remains one of the world’s most severe environmental health crises, with naturally mobilized arsenic exceeding guideline values across large parts of the Bengal Basin. Millions of people draw their drinking water from shallow tube wells, and chronic exposure to inorganic arsenic has been linked to dermatological, cardiovascular, neurological, and carcinogenic effects even at concentrations close to regulatory thresholds. National survey data show extensive regions where concentrations surpass the World Health Organization guideline of 10 micrograms per liter. Against this backdrop, researchers have now designed and computationally optimized a compact optical sensor that could bring sensitive, label-free arsenic monitoring closer to the communities that need it most, without the centralized laboratory infrastructure that conventional testing demands.
Traditional arsenic quantification relies on techniques such as atomic absorption spectrometry, inductively coupled plasma mass spectrometry, and ion chromatography. These methods deliver excellent sensitivity and speciation capability, but they require sophisticated instrumentation and trained personnel, which limits routine, high-frequency surveillance across dispersed rural wells. Portable electrochemical and colorimetric assays have been deployed in national screening programs, yet they often demand chemical pre-treatment, suffer matrix-dependent interference, or lack the quantitative precision needed for long-term monitoring and remediation validation. Optical approaches such as fluorometric and colorimetric platforms respond rapidly and can be portable, but many depend on specialized reagents, complex surface functionalization, or indirect detection mechanisms that can undermine long-term stability and selectivity in the field.
The new study, published in Results in Optics, turns to surface plasmon resonance, a label-free optical technique with real-time response and exceptional sensitivity to refractive-index variations at a metal-dielectric interface. In the classic Kretschmann configuration, a p-polarized beam passing through a high-index prism excites a surface plasmon polariton at a thin metallic layer, and any change in the adjacent aqueous refractive index is translated into a measurable shift of the resonance angle. Surface plasmon resonance has long been applied to chemical and biomedical sensing, including prior arsenic quantification, but achieving simultaneously high sensitivity, narrow resonance linewidth, and a strong quality factor remains a major challenge when the refractive-index perturbations associated with contamination are small.
The research team, led by Khandoker Tauhid Imam with Masiath Ibna Jamil and Md. Aminur Rahman, addressed three gaps that persist in the literature. Most optimized multilayer plasmonic sensors target biomedical or generic water-quality scenarios rather than groundwater arsenic specifically. Comparative studies evaluating multiple optimization algorithms on the same multilayer platform are scarce, limiting insight into how different strategies trade off sensitivity, resonance sharpness, and fabrication feasibility. And few studies have explored low-cost copper-based architectures that balance a high quality factor, narrow linewidth, and manufacturability. To fill these gaps, the team designed an S-FPL53 prism/MgF2/Cu/Ni/ZnSe multilayer stack that combines dielectric-assisted coupling with bimetallic plasmonic confinement, and subjected it to a rigorous computational design pipeline.
The theoretical backbone of the work is the transfer matrix method, which provides an exact closed-form solution for wave propagation in stratified planar media and can rapidly evaluate reflection spectra for thousands of candidate thickness combinations. In the Kretschmann geometry, resonance occurs when the in-plane component of the incident wavevector matches the surface plasmon polariton wavevector at the metal-dielectric boundary. Sweeping the incidence angle at a fixed wavelength of 632.8 nanometers identifies the resonance minimum from which the resonance angle and full width at half maximum are extracted, feeding into standard performance metrics: angular sensitivity, detection accuracy, quality factor, figure of merit, and a refractive-index limit of detection. To guard against numerical artifacts, the team independently cross-validated all resonance characteristics with finite-element simulations in COMSOL Multiphysics, which solve the full boundary-value problem of Maxwell’s equations without assuming planar layering. The two methods agreed closely on resonance angles, linewidths, and field distributions, and the field maps revealed strong confinement at the Cu/Ni-ZnSe boundary with an evanescent penetration depth of roughly 209 nanometers into the analyte, sufficient to probe the bulk aqueous medium.
A critical modeling step involved estimating the refractive index of arsenic-doped water. Experimental calibration data from a photonic-crystal-fiber SPR study supplied refractive indices for arsenic concentrations between 0.1 and 0.5 percent, and the team extrapolated to 1.0 percent using linear regression, quadratic regression, and a rate-based method. The quadratic model proved most reliable, achieving a coefficient of determination of 0.9975 and a root mean square error of 4.81 by 10 to the minus 6, predicting a refractive index of about 1.3474 at 1.0 percent. Leave-one-out cross-validation and a 95 percent prediction interval confirmed the stability of this extrapolation, although the authors honestly note that the five-point dataset remains limited and that direct measurements at higher concentrations are a priority for future work. They are equally transparent that the laboratory calibration concentrations are roughly five orders of magnitude higher than the parts-per-billion levels of the WHO guideline, so the study should be read as a demonstration of refractive-index sensitivity and optimization methodology rather than a direct simulation of field-realistic arsenic levels.
Within the specified refractive-index window from 1.330 for pure water to 1.3474, the manually tuned baseline sensor performed strongly. The resonance dip sat at 79.78 degrees for pure water and shifted progressively to 85.70, 85.86, and 86.34 degrees as arsenic-derived refractive indices rose, yielding sensitivities of 361.42, 365.17, and 377.01 degrees per refractive-index unit with linewidths of only about 2.4 to 2.6 degrees. The SNR-limited refractive-index detection limit remained near 1.1 by 10 to the minus 6 RIU across all concentrations. Comparative screening showed that the low-index Ohara S-FPL53 prism nearly tripled the sensitivity of a conventional BK7 prism, that copper outperformed silver in figure of merit by more than an order of magnitude while matching its sensitivity, and that thickness sweeps identified roughly 50-nanometer copper and 2-nanometer ZnSe as the sweet spots balancing sensitivity against resonance sharpness. Against published aqueous SPR sensors operating near the water refractive-index region, the design’s 377 degrees per RIU was the highest angular sensitivity reported among the compared structures.
The centerpiece of the study, however, is a head-to-head comparison of three metaheuristic algorithms, Differential Evolution, Particle Swarm Optimization, and a Genetic Algorithm, all run with identical population sizes of 30, identical generation counts of 40, identical search bounds, and the same transfer-matrix fitness evaluation. Differential Evolution and Particle Swarm Optimization converged to nearly identical thickness configurations, with copper near 59.3 nanometers, nickel at 1 nanometer, and ZnSe at 2 nanometers, and delivered the sharpest resonances: quality factors up to 67.64, figures of merit approaching 202 per RIU, and linewidths narrowed to about 1.22 degrees. The Genetic Algorithm instead pushed angular sensitivity beyond 308 degrees per RIU at the cost of broader dips and lower quality factors. Across 25 independent runs, DE and PSO converged rapidly with minimal variability, standard deviations of 0.0051 and 0.3019 respectively, while GA varied far more, with a standard deviation of 6.0231. A multi-objective Differential Evolution run further improved average figure of merit and quality factor by 51.57 percent and 169.45 percent at the expense of a 33.89 percent sensitivity reduction, giving designers a tunable trade-off between spectral resolution and raw sensitivity.
Fabrication feasibility and robustness were examined in detail. Every layer can be produced with mature thin-film techniques: thermal or electron-beam evaporation and atomic layer deposition for the magnesium fluoride spacer, magnetron sputtering for copper, RF sputtering for the protective nickel cap, and evaporation, sputtering, or chemical vapor deposition for ZnSe. A tolerance analysis with plus-or-minus 5 and 10 percent thickness perturbations showed that the magnesium fluoride layer is essentially immune to error, that copper thickness most strongly governs resonance sharpness and quality factor, and that the ultrathin nickel and ZnSe films are most critical per nanometer for preserving sensitivity, underscoring the value of atomic-scale deposition control for the thinner layers. Even under worst-case simultaneous minus-10 percent deviations the sensor retained a sensitivity above 311 degrees per RIU, while positive deviations pushed performance as high as 443.79 degrees per RIU.
The authors are careful about the road to deployment. Because the structure transduces bulk refractive index rather than binding arsenic specifically, selective quantification in real groundwater, which contains iron, manganese, bicarbonate, dissolved organic matter, and other constituents, will require complementary surface functionalization, reference-channel compensation, or multivariate calibration. Temperature fluctuations alone shift the refractive index of water by roughly 1 by 10 to the minus 4 RIU per degree Celsius, comparable to the signals of low arsenic concentrations, so field instruments will need thermal compensation, vibration-stable angular interrogation or a move toward fixed-angle schemes, and periodic recalibration against arsenic-free references, ideally on low-power solar-supplemented electronics suited to rural Bangladesh. Even so, the combination of a low-cost copper plasmonic layer rather than gold, sharp optimized resonances, demonstrated fabrication tolerance, and a transparent, reproducible optimization framework makes this multilayer design a compelling transduction platform. With appropriate arsenic-selective chemistry layered on top, the same architecture could ultimately serve decentralized tube-well screening, and the authors plan experimental fabrication, stability testing, and validation with real groundwater samples from arsenic-affected regions as the next steps.
Subject of Research: Metaheuristic optimization of a multilayer surface plasmon resonance sensor for arsenic monitoring in groundwater in Bangladesh
Article Title: Comparative metaheuristic optimization of a multilayer SPR sensor for arsenic monitoring in groundwater in Bangladesh
Article References: Imam, K. T., Jamil, M. I., & Rahman, M. A. (2026). Comparative metaheuristic optimization of a multilayer SPR sensor for arsenic monitoring in groundwater in Bangladesh. Results in Optics, 25, Article 101134. https://doi.org/10.1016/j.rio.2026.101134
Image Credits: AI Generated
DOI: 10.1016/j.rio.2026.101134
Keywords: surface plasmon resonance, arsenic detection, groundwater, Bangladesh, metaheuristic optimization, Differential Evolution, Particle Swarm Optimization, Genetic Algorithm, copper plasmonics, refractive index sensing, Kretschmann configuration, water quality monitoring
