Every time a worker picks up a hammer drill, a nail gun, or any other vibrating hand tool, an invisible negotiation begins between machine and body. The tool shakes, the hand stiffens, and the arm decides—through its muscles, tendons, and soft tissues—how much of that shaking energy to absorb. A new study published in Results in Engineering has now mapped this negotiation with unprecedented detail, showing that the forces a person applies to a tool handle can change how strongly the hand-arm system resists vibration by a factor of up to fifteen at the same frequency, and how much vibrational energy it soaks up by a factor of up to eight. The findings could reshape how engineers design safer power tools and how regulators assess vibration risk in the workplace.
The research team, led by Carina Spengler and Simon Saurbier at the Karlsruhe Institute of Technology together with colleagues including Andreas Lindenmann, Dieter Krause, and Sven Matthiesen, tackled a stubborn gap in the science of hand-arm vibration. Prolonged exposure to tool vibration is a well-documented occupational hazard, linked to vascular, neurological, and musculoskeletal disorders, including the painful condition known as white finger syndrome. The international standard ISO 5349-1 governs how this exposure is measured, and a companion standard, ISO 10068:2012, provides reference values for the mechanical impedance of the hand-arm system—the ratio of dynamic force to vibration velocity at the point where the hand grips the handle. But those reference values were built on limited grip and push force ranges, and earlier studies typically tested only a handful of force combinations with small groups of subjects.
What makes the new work stand out is its systematic scope. Rather than testing two or three discrete force settings, the team measured the biodynamic response across a full ten-by-ten grid of grip and push forces, with grip forces spanning 10 to 135 newtons and push forces spanning 10 to 110 newtons. Five subjects—three men and two women aged 23 to 34—each completed 300 measurements over multiple sessions spread across roughly twelve days, with the order of force combinations randomized to guard against fatigue and learning effects. In total, 1500 measurements were recorded on a test rig equipped with two electromechanical shakers, one axial and one rotational, driving a standardized cylindrical measuring handle instrumented with one-axial and three-axial force sensors and accelerometers.
The excitation itself was engineered for efficiency and safety. Instead of sweeping through frequencies one at a time, the shaker delivered a multisine signal—a superposition of sine waves from 10 to 500 hertz in 5-hertz steps—which compressed each measurement to just 16.5 seconds. The unweighted root-mean-square acceleration was 30 meters per second squared, far higher than the 2.5 to 9 meters per second squared typical of earlier single-sine studies, and the calculated total vibration value of 6.5 meters per second squared per measurement remained well below the exposure limits that would trigger protective measures. Subjects watched a real-time graphical display of their applied grip and push forces against the targets, adjusting their effort as needed, and any measurement deviating more than 5 newtons or 14 percent from the target was discarded—150 of the 1500 recordings failed this test.
Two quantities anchored the analysis. The mechanical impedance, expressed in newton-seconds per meter, describes how the hand-arm system dynamically resists motion: its real part reflects energy dissipated per unit time, while its imaginary part captures energy that is reversibly stored and returned. The vibration power absorption, measured in watts, is derived from the real part of the impedance and the squared vibration velocity, and quantifies the actual mechanical power flowing into the body. Both were evaluated along the translational z-axis of the hand-arm system, the direction defined in ISO 5349-1 as the primary axis of exposure assessment.
The results reveal a striking frequency-dependent choreography. Within a single subject, varying the grip and push forces broadened the median impedance magnitude from values between roughly 100 and 430 newton-seconds per meter into a range spanning 50 to 950 newton-seconds per meter across the measured frequencies; for one subject the spread reached a 15.8-fold increase at 50 hertz. Grip force proved the dominant parameter, strongly influencing impedance between 30 and 70 hertz and again above 160 hertz, with a maximum difference of 318 newton-seconds per meter at 40 hertz and a difference of 290 newton-seconds per meter persisting even at 500 hertz. Push force mattered most in the mid-range between 50 and 110 hertz, peaking at 177 newton-seconds per meter at 55 hertz, but its influence faded above 160 hertz—consistent with the fact that grip is generated by the hand and forearm while push originates from the shoulder, and high-frequency vibrations barely propagate beyond the hand itself.
The power absorption data told an equally nuanced story. Most of the absorbed energy concentrated below 60 hertz, precisely the range in which hand-held tools transmit the most vibration to the body, and the curves peaked between 35 and 40 hertz before collapsing toward zero above 100 hertz. Higher forces generally increased absorption, but in a narrow low-frequency window—roughly 10 to 30 hertz—the trend reversed, with stronger grips actually reducing the energy absorbed. The researchers attribute this to stiffening: as muscle contraction increases, the hand-arm system becomes a harder spring, reflecting more energy rather than dissipating it, while simultaneously improving mechanical coupling that channels more vibration into the arm at higher frequencies. Notably, the two female subjects showed lower impedance values above 100 hertz and different resonance features than the male subjects, echoing earlier reports that anthropometry and sex-related differences shape the biodynamic response.
Perhaps the most practically consequential finding concerns prediction. Because the force-dependent curves proved approximately linear at nearly every frequency, the team tested whether intermediate force levels could be interpolated from a small number of measured reference curves. The answer was emphatic: with just three carefully spaced grid curves, linear interpolation predicted both impedance magnitude and power absorption at intermediate forces with a mean absolute percentage error below 5 percent, corresponding to roughly 95 percent accuracy. Adding a fourth curve improved matters further—dropping the mean error for impedance to 3.29 percent—but with diminishing returns, and the largest accuracy gain came from moving from two to three curves. For future experiments, this means the grueling full-grid protocol may be unnecessary: a handful of reference force levels, distributed across the range of interest, could capture the essential behavior while dramatically reducing the burden on human subjects.
The study also delivers a pointed critique of the existing standard. When the measured impedance curves were compared against the ISO 10068:2012 reference range, they frequently fell outside it, especially between 20 and 100 hertz and above 250 hertz—exactly the frequency bands where grip and push forces exert their strongest influence. The authors argue that interaction forces should therefore not be treated as a fixed boundary condition in vibration analysis but as an explicit modeling parameter, one that varies continuously during real tool use. Their data, published as an open dataset, and their interpolation framework pave the way for physical and simulation-based hand-arm models that incorporate user forces directly—enabling virtual testing of tools before prototypes exist, robotic replication of human dynamics, and ultimately the design of machines that shake less hard on the people who hold them.
Subject of Research: Effects of grip and push force variations on the mechanical impedance and vibration power absorption of the human hand-arm system
Article Title: Modeling the influence of grip and push force variations on the mechanical impedance and vibration power absorption of the hand-arm system
Article References: Spengler, C., Saurbier, S., Lindenmann, A., Doellken, M., Bunk, L., Krause, D., & Matthiesen, S. (2026). Modeling the influence of grip and push force variations on the mechanical impedance and vibration power absorption of the hand-arm system. Results in Engineering, 32, Article 113151. https://doi.org/10.1016/j.rineng.2026.113151
Image Credits: AI Generated
DOI: 10.1016/j.rineng.2026.113151
Keywords: hand-arm vibration, mechanical impedance, vibration power absorption, grip force, push force, biodynamics, power tools, occupational health, ISO 10068, vibration exposure, interpolation, human-machine systems
